| Product properties | Product type: Relay socket Product family: RIFLINEÃcomplete |
| Electrical properties | Nominal voltage UN: 250 V AC/DC Nominal current IN: 4x 6 A Protective circuit: depending on the selected input/suppressor modules |
| Connection data | Connection method: Push-in connection Stripping length: 8 mm Conductor cross section rigid: 0.14 mm² ... 1.5 mm² Conductor cross section flexible: 0.14 mm² ... 1.5 mm² 0.14 mm² ... 1.5 mm² (Ferrule with plastic sleeve) 0.14 mm² ... 1 mm² (Ferrule with plastic sleeve, two conductors on double terminal block) Conductor cross section AWG: 26 ... 16 (solid) 26 ... 16 (flexible) |
| Dimensions | Width: 31 mm Height: 96 mm Depth Retaining bracket: 75 mm (with retaining bracket) |
| Material specifications | Flammability rating according to UL 94: V2 (Housing) |
| Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -40°C ... 60°C (Related to the assembly) Ambient temperature (storage/transport): -40°C ... 85°C |
| Approvals | Corrosive gas test Identification: ISA-S71.04. G3 Harsh Group ENÃ60068-2-60 |
| Mounting | Mounting type: DIN rail mounting Mounting position: any |
