1403984 PHOENIX CONTACT -

SAC-4P-M12MS/10,0-600 SH HD - Sensor/actuator cable

Sensor/actuator cable, 4-position halogen-free, shielded, Plug straight M12, coding: A, connected with unwired, on free cable end, cable length: 10 m, Hygienic design, with high-grade steel knurl

Product Code: 1403984 copia - copy

Partner cod.: 1403984 copia - copy

PHOENIX CONTACT

Product properties	Product type: Sensor/actuator cable Number of positions: 4 Application: Food processing industry No. of cable outlets: 1 Shielded: yes Coding: A Insulation characteristics Overvoltage category: II Degree of pollution: 3
Material specifications	Material of grip body: PP Contact material: CuSn Contact surface material: Ni/Au Contact carrier material: PP Material for screw connection: Stainless steel
Electrical properties	Contact resistance: Ã¢Ã¢°¤ 5 mÃ© Insulation resistance: Ã¢Ã¢°¥ 100 MÃ© Nominal voltage U_N: 48 VÃAC 60 VÃDC Nominal current I_N: 4 A Protective circuit: unwired
Mechanical properties	Mechanical data Insertion/withdrawal cycles: Ã¢Ã¢°¥ 100
Signaling	Status display: No Status display present: No
Connection data	Conductor connection Tightening torque: 0.4 Nm (M12 connector)
Connector	Connection 1 Type: Plug straight M12 Number of positions: 4 Coding type: A Connection 2 Type: free cable end
Cable/line	Cable length: 10 m Halogen-free PP gray shieldedÃ[600] Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/d51539ce4a06a04793e1e0ba94747f43/-S204x204-FJPG Cable weight: 40 kg/km Number of positions: 4 Shielded: yes Cable type: Halogen-free PP gray shieldedÃ[600] Conductor structure signal line: 42x 0.10 mm AWG signal line: 22 Conductor cross section: 4x 0.34 mm² (Signal line) Wire diameter incl. insulation: 1.27 mm Ã±0.02Ãmm (Signal line) External cable diameter: 5.55 mm Ã±0.2Ãmm Outer sheath, material: PP-EPDM External sheath, color: gray RAL 7035 Conductor material: Bare Cu litz wires Material wire insulation: PP Single wire, color: brown, white, blue, black Thickness, insulation: Ã¢Ã¢°¥ 0.21 mm (Core insulation) Thickness, outer sheath: approx. 0.8 mm Overall twist: 4 wires, twisted Length of twist, overall twist: 48 mm Optical shield covering: 85 % Max. conductor resistance: 58 Ã©/km (at 20Ã°C) Nominal voltage, cable: Ã¢Ã¢°¤ 300 VÃAC Test voltage: Ã¢Ã¢°¥ 3000 VÃAC (Spark test) Test voltage Core/Shield: Ã¢Ã¢°¥ 2000 VÃAC (for 60 s) Minimum bending radius, fixed installation: 5 x D Minimum bending radius, flexible installation: 10 x D Max. bending cycles: 2000000 Halogen-free: in accordance with DINÃVDEÃ0472 partÃ815 Other resistance: Resistant to cold bending and cold impacts according to DINÃENÃ60811-1-4 (-40Ã°C) Special properties: FDA compliant according to FDA 21 CFR 177.2600 flexible Flexible cable conduit capable Ambient temperature (operation): -40°C ... 105°C (cable, fixed installation) -25°C ... 105°C (Cable, flexible installation)
Environmental and real-life conditions	Ambient conditions Degree of protection: IP65 IP67 IP68 IP69K Ambient temperature (operation): -40°C ... 105°C (Plug / socket)
Standards and regulations	M12 Standard designation: M12 connector Material conformance Standards/specifications: IEC 61076-2-101 FDA 21 CFR 177.2600
