| Product properties | Product type: Data cable by the meter Sensor type: PROFINET Number of positions: 4 Application: Robots and drag chains Shielded: yes |
| Electrical properties | Transmission medium: Copper |
| Interfaces | Signal type/category: PROFINET CAT5 (IEC 11801:2002), 100 Mbps |
| Connector | Connection 1 Type: free cable end Connection 2 Type: free cable end |
| Cable/line | Cable length: 100 m PROFINET robot CAT5Ã[93R] Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/332e7b7c0f61684089bb5f28ed260786/-S204x204-FJPG Cable weight: 55 kg/km UL AWM Style: 20233 (80°C/300 V) Number of positions: 4 Shielded: yes Cable type: PROFINET robot CAT5Ã[93R] Conductor structure: 1x4xAWG22/19, S/TQ Signal runtime: 4.8 ns/m Conductor structure signal line: 19x 0.15 mm AWG signal line: 22 Conductor cross section: 4x 0.34 mm² Wire diameter incl. insulation: 1.5 mm External cable diameter: 6.5 mm ñ0.2Ãmm Outer sheath, material: PUR External sheath, color: green RAL 6018 Conductor material: Tin-plated Cu litz wires Material wire insulation: Foamed PE Single wire, color: white, yellow, blue, orange Thickness, outer sheath: approx. 1 mm Overall twist: Star quad Optical shield covering: 85 % Insulation resistance: ââ°¥ 500 Mé*km Loop resistance: ââ°¤ 120.00 é/km Wave impedance: 100 é ñ5Ãé (at 100 MHz) Nominal voltage, cable: 300 V Test voltage Core/Core: 2000 V (50ÃHz, 1Ãmin.) Test voltage Core/Shield: 2000 V (50ÃHz, 1Ãmin.) Minimum bending radius, fixed installation: 5 x D Torsion force: ñ 180°/m Torsion cycles: 1000000 Shield attenuation: 2.9 dB (with 1 MHz) 5 dB (at 4 Ãà Hz) 8.1 dB (at 10 MHz) 10.4 dB (at 16 MHz) 11.9 dB (at 20ÃÃà Hz) 15.5 dB (at 31.25ÃÃà Hz) 26.5 dB (at 62.5ÃÃà Hz) 41 dB (at 100 MHz) Halogen-free: according to IEC 60754-1 Flame resistance: according to IEC 60332-1-2 Resistance to oil: in accordance with DINÃENÃ60811-2-1 Other resistance: UV resistant According to ULÃ1581, Section 1200 Ambient temperature (operation): -40°C ... 80°C Ambient temperature (installation): -20°C ... 60°C |
