| Product properties | Product type: System cable |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP00 Degree of protection (Installation location): ââ°¥ IP54 (Installation location) Ambient temperature (operation): -40°C ... 70°C (fixed installation) -10°C ... 70°C (flexible installation) Ambient temperature (storage/transport): -40°C ... 80°C Altitude: ââ°¤ 2000 m |
| Electrical properties | Operating voltage (DC): ââ°¤ 30 VÃDC Nominal operating mode: 100% operating factor Current (Per path): ââ°¤ 500 mA (uncoiled) Supported controller YOKOGAWA CS3000 CentumVP Suitable I/O card: ADV161 ADV561 Supported controller YOKOGAWA STARDOM Suitable I/O card: NFDV161 NFDV561 |
| Cable/line | Cable length: 15 m 50X0.14Ã[PVC] UL AWM Style: 2464/1061 Number of positions: 50 Shielded: yes Cable type: 50X0.14Ã[PVC] Conductor type: Assembled shielded round cable Conductor structure signal line: 7x 0.16 mm AWG signal line: 26 Conductor cross section: 50x 0.14 mm² Wire diameter incl. insulation: 1 mm ñ0.03Ãmm External cable diameter: 11 mm ñ0.3Ãmm Outer sheath, material: Semi-rigid PVC External sheath, color: gray Conductor material: Tin-plated Cu litz wires Cable resistance: ââ°¤ 145 é/km (at 20ðC) Insulation resistance: ââ°¥ 20 Mé*km (20ðC) Smallest bending radius, fixed installation: 114 mm Smallest bending radius, movable installation: 205 mm Max. bending cycles: 5000 (at a radius of ââ°¥ 18x outside diameter) Halogen-free: no Flame resistance: IEC 60332-1-2 (raw cable) VDEÃ0842, PartÃ332-1-2 (raw cable) IEC 60332-3-22 (raw cable) ULÃVW-1 CSA FT-1 Resistance to oil: can withstand occasional splashes (raw cable) |
| Connection data | Connection 1 Connection in acc. with standard: based on IEC 60603-13 Connection method: IDC/FLK socket strip Number of connections: 1 Number of positions: 50 Insertion/withdrawal cycles: > 50 Pitch: 2.54 mm Connection 2 Connection in acc. with standard: based on IEC 60603-13 Connection method: Yokogawa, KS compatible Number of connections: 1 Number of positions: 50 Tightening torque: 0.5 Nm (Screw connection) Insertion/withdrawal cycles: > 50 Pitch: 2.54 mm Fixing to IO cards Connection method: Screw connection Tightening torque: 0.5 Nm |
| Notes | General: For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met. |
