| Product properties | Product type: Relay Module Product family: PLC-INTERFACE Operating mode: 100% operating factor Mechanical service life: approx. 3x 107 cycles Data management status Date of last data management: 08.07.2024 Article revision: 04 Insulation characteristics Insulation: Basic insulation |
| Electrical properties | Maximum power dissipation for nominal condition: 0.48 W Test voltage (Winding/contact): 4 kV AC (50 Hz, 1 min., winding/contact) Rated insulation voltage: 250 V AC Rated surge voltage: 4 kV |
| Input data | Coil side Nominal input voltage UN: 48 V AC/DC (50/60 Hz) Input voltage range: 38.4 V AC/DC ... 60 V AC/DC (20 °C) Nominal voltage (plugged-in electromechanical relay): 24 V DC Drive and function: monostable Drive (polarity): polarized Typical input current at UN: 10 mA (At UN = 48 V AC) 9.2 mA (At UN = 48 V DC) Typical response time: 6 ms Typical release time: 15 ms Protective circuit: Bridge rectifier; Bridge rectifier Operating voltage display: Yellow LED |
| Output data | Switching Contact switching type: 1 changeover contact Type of switch contact: Single contact Contact material: AgSnO, hard gold-plated Note: If the specified maximum values are exceeded, the gold plating is destroyed. The AgNi contact values are then valid for further operation; a reduction in length of service life is to be expected. Maximum switching voltage: 30 V AC 36 V DC Minimum switching voltage: 100 mV (at 10 mA) Limiting continuous current: 50 mA Maximum inrush current: 50 mA Min. switching current: 1 mA (24 V) Short-circuit current: 200 A (conditional short-circuit current) Interrupting rating (ohmic load) max.: 1.2 W (at 24 V DC) Output fuse: 4 A gL/gG NEOZED Switching capacity: 3 A (230 V (AC 15)) Switching: when the gold layer is destroyed Note: the following values are applicable if a gold layer is destroyed Maximum switching voltage: 250 V AC/DC Minimum switching voltage: 5 V (at 100 mA) Limiting continuous current: 6 A Min. switching current: 10 mA (at 12 V) Interrupting rating (ohmic load) max.: 140 W (at 24 V DC) 20 W (at 48 V DC) 18 W (at 60 V DC) 23 W (at 110 V DC) 40 W (at 220 V DC) 1500 VA (for 250 V AC) |
| Connection data | Connection method: Push-in connection Stripping length: 10 mm Conductor cross section rigid: 0.14 mm² ... 2.5 mm² Conductor cross section flexible: 0.14 mm² ... 2.5 mm² 0.2 mm² ... 2.5 mm² (Single ferrule) 2x 0.5 mm² ... 1 mm² (TWIN ferrule) Conductor cross section AWG: 26 ... 14 |
| Dimensions | Width: 6.2 mm Height: 80 mm Depth: 86 mm |
| Material specifications | Color: gray (RAL 7042) |
| Environmental and real-life conditions | Ambient conditions Degree of protection (Relay base): IP20 (Relay base) Ambient temperature (operation): -20 °C ... 60 °C Ambient temperature (storage/transport): -20 °C ... 60 °C |
| Approvals | CE Certificate: CE-compliant UKCA Certificate: UKCA-compliant Shipbuilding approval Certificate: TAE0000196 Corrosive gas test Identification: ISA-S71.04. G3 Harsh Group EN 60068-2-60 DNV GL data Temperature: D Humidity: A Vibration: B/C EMC: B Enclosure: Required protection according to the Rules shall be provided upon installation on board |
| EMC data | Electromagnetic compatibility: Conformance with EMC directive Low Voltage Directive: Conformance with Low Voltage Directive |
| Standards and regulations | Standards/regulations: IEC 60947-5-1 |
| Mounting | Mounting type: DIN rail mounting Assembly note: in rows with zero spacing Mounting position: any |
