2903173 PHOENIX CONTACT -

Product properties	Product type: Solid-state relay module Product family: PLC-INTERFACE Application: Pulse stretching Operating mode: 100% operating factor Insulation characteristics Insulation: Basic insulation Insulation characteristics: Air clearances and creepage distances between the power circuits Insulation: Basic insulation Overvoltage category: II Pollution degree: 2
Electrical properties	Maximum power dissipation for nominal condition: 0.07 W Test voltage (Input/output): 2.5 kV_rms (50ÃHz, 1Ãmin., input/output) Air clearances and creepage distances between the power circuits Rated insulation voltage: 50 VÃDC Rated surge voltage: 0.5 kV
Input data	Rated control circuit supply voltage U_S: 24 VÃDC Voltage range with reference to U_S: 0.8 ... 1.2 Rated control supply current I_S: 13 mA (Input low, output low) 19 mA (Input high, output high) Rated actuating voltage U_C: 24 VÃDC Rated actuating current I_C: 3 mA Input voltage range: 19.2 VÃDC ... 28.8 VÃDC "0" signal switching threshold in reference to U_C: < 0.4 "1" signal switching threshold in reference to U_C: > 0.8 Status display: Yellow LED Operating voltage display: Green LED Protective circuit: Reverse polarity protection Surge protection Surge voltage protection: > 33 VÃDC
Output data	Contact switching type: 1 N/O contact Design of digital output: electronic Output voltage range: 3 VÃDC ... 48 VÃDC Limiting continuous current: 100 mA Surge voltage protection: > 54 VÃDC Voltage drop at max. limiting continuous current: < 1 VÃDC Output circuit: 3-conductor, ground-referenced Protective circuit: Reverse polarity protection Surge protection Free running
Connection data	Connection method: Push-in connection Stripping length: 10 mm Conductor cross section rigid: 0.14 mm² ... 2.5 mm² Conductor cross section flexible: 0.14 mm² ... 2.5 mm² 0.2 mm² ... 2.5 mm² (Single ferrule) 2x 0.5 mm² ... 1 mm² (TWIN ferrule) Conductor cross section AWG: 26 ... 14
Dimensions	Width: 6.2 mm Height: 80 mm Depth: 86 mm
Environmental and real-life conditions	Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -25°C ... 60°C Ambient temperature (storage/transport): -25°C ... 75°C
Approvals	Corrosive gas test Identification: ISA-S71.04. G3 Harsh Group ENÃ60068-2-60
Standards and regulations	Air clearances and creepage distances between the power circuits Standards/regulations: IEC 60947-5-1
Mounting	Mounting type: DIN rail mounting Assembly instructions: in rows with zero spacing Mounting position: any
