2903599 PHOENIX CONTACT -

Product properties	Product type: Interface module Product family: VARIOFACE Professional Number of positions: 16
Electrical properties	Nominal voltage U_N: 24 VÃDC Max. current carrying capacity per branch: 63 mA (in as supplied state, with one 63 mA fuse) Supported controller EMERSON DeltaV Suitable I/O card: VE4003S2B4 VE4005S2B3 VE4003S2B5 SE4003S2B4
Connection data	Field level Connection method: Push-in connection Stripping length: 8 mm Conductor cross section rigid: 0.14 mm² ... 2.5 mm² Conductor cross section flexible: 0.14 mm² ... 2.5 mm² Conductor cross section AWG: 26 ... 14 Controller level Connection method: IDC/FLK pin strip Number of connections: 1 Number of positions: 16 Pitch: 2.54 mm
Signaling	Status display present: Yes, if the fuse fails
Dimensions	Item dimensions Width: 57.1 mm Height: 110.8 mm Depth: 62.9 mm
Environmental and real-life conditions	Ambient conditions Ambient temperature (operation): -20°C ... 60°C Ambient temperature (storage/transport): -20°C ... 70°C
Standards and regulations	Standards/regulations: DINÃENÃ50178
Mounting	Mounting type: DIN rail mounting Mounting position: any
Notes	General: For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met. Trade restriction CE note: The products are offered exclusively for export outside the EU and the European Economic Area.
