| Product properties | Product type: System cable |
| Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -20°C ... 50°C Ambient temperature (storage/transport): -20°C ... 70°C |
| Electrical properties | Operating voltage (AC): ââ°¤ 125 VÃAC Operating voltage (DC): ââ°¤ 125 VÃDC Current (Per path): ââ°¤ 2 A |
| Cable/line | Cable length: 3 m Number of positions: 25 Shielded: yes Conductor type: Assembled shielded round cable AWG signal line: 22 Conductor cross section: 25x 0.36 mm² External cable diameter: 10.4 mm Halogen-free: no color code D-SUB25 (1): () = black D-SUB25 (2): () = white D-SUB25 (3): () = red D-SUB25 (4): () = green D-SUB25 (5): () = orange D-SUB25 (6): () = blue D-SUB25 (7): () = white-black D-SUB25 (8): () = red-black D-SUB25 (9): () = green-black D-SUB25 (10): () = orange-black D-SUB25 (11): () = blue-black D-SUB25 (12): () = black-white D-SUB25 (13): () = red-white D-SUB25 (14): () = green-white D-SUB25 (15): () = blue-white D-SUB25 (16): () = black-red D-SUB25 (17): () = white-red D-SUB25 (18): () = orange-red D-SUB25 (19): () = blue-red D-SUB25 (20): () = red-green D-SUB25 (21): () = orange-green D-SUB25 (22): () = black-white D-SUB25 (23): () = white-black D-SUB25 (24): () = red-black D-SUB25 (25): () = green-black |
| Connection data | Field level Connection method: D-SUB pin strip Number of connections: 1 Number of positions: 25 Controller level Connection method: Single wires Number of positions: 25 Note: The wires are marked and fitted with ferrules |
| Notes | General: For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met. |
