| Product properties | Product type: Connector |
| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/0d7eeb06ce1f1c41a1fcbdfb00b40e06/-S204x204-FJPG Width: 36 mm Length of the insulating material sleeve: 28 mm Maximum stripping length: 31 mm Distance from the center to the insulating material sleeve: 22 mm Min. material thickness: 3.5 mm Inner dimensions of the insulating collar: 21 mm Internal dimensions Internal diameter: 10.5 mm |
| Material specifications | Color: silver Material: Copper Coating: tin-plated |
| Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): 110°C |
| Standards and regulations | Design according to standard: DINÃ46234 |
