2905203 PHOENIX CONTACT -

TC-2KS40-AI16-EX-PR-RS - Module carrier

Termination Carrier for redundantly connecting 16 MACX Analog Ex i repeater power supplies and input signal conditioners or Ex i temperature transducers to analog input cards of the Yokogawa ProSafe-RS controller, via two KS40 connectors, 40-pos. Suitable for Yokogawa SAI143 card.

Product Code: 2905203 copia - copy

Partner cod.: 2905203 copia - copy

PHOENIX CONTACT

Notes	General: For proper use, the specifications of the installation directive (see Downloads) must be observed. For applications or use with third-party products, the specifications, and the safety and warning instructions of the respective third-party manufacturer must also be met.
Product properties	Product type: Module carrier Insulation characteristics Insulation: Basic insulation Insulation characteristics: Air clearances and creepage distances Insulation: Basic insulation Overvoltage category: II Pollution degree: 2
Electrical properties	Max. permissible current: 1 A (Signal/channel) Nominal voltage U_N: < 30 VÃDC (Per signal/channel) Air clearances and creepage distances Rated insulation voltage: 50 V Rated surge voltage: 0.5 kV Supported controller YOKOGAWA ProSafe-RS Suitable I/O card: SAI143 Supply Designation: Power module Note: Power supply via 2904673 TC-MACX-MCR-PTB power supply and error signaling module. Fuse: 2x 2.5 A on PCB, slow-blow (replaceable) Input voltage: 24 VÃDC Input voltage range: 19.2 VÃDC ... 30 VÃDC Input current: Ã¢Ã¢°¤ 2 A Redundant supply: yes, decoupled from diodes Polarization and surge protection: Yes Output name: Switching output Contact switching type: 1 N/C contact (alarm = open) Maximum switching voltage: 50 VÃDC (0.3ÃA) 30 VÃDC (2ÃA) 33 VÃAC (2ÃA)
Connection data	Power supply Connection method: Screw connection Stripping length: 7 mm Number of connections: 1 Number of positions: 6 Conductor cross section rigid: 0.14 mm² ... 2.5 mm² Conductor cross section flexible: 0.14 mm² ... 2.5 mm² Conductor cross section AWG: 24 ... 12 Controller level Connection method: Yokogawa KS-compatible Number of connections: 2 Number of positions: 40
Signaling	Status display: 1 x red LED (error) 2x green LEDs (PWR1 and PWR2)
Dimensions	Width: 242 mm Height: 170 mm Depth: 159.5 mm
Material specifications	Flammability rating according to UL 94: V0
Environmental and real-life conditions	Ambient conditions Degree of protection: IP00 Ambient temperature (operation): -20°C ... 60°C (Please observe module specifications) Ambient temperature (storage/transport): -40°C ... 80°C Altitude: Ã¢Ã¢°¤ 2000 m Permissible humidity (operation): 5 % ... 95 % (non-condensing) Shock: 15g, according to IECÃ½60068-2-27 Vibration (operation): 2g, according to IEC 60068-2-6
Approvals	UL, USA/Canada Identification: UL 61010 Listed Class I, Div. 2, Groups A, B, C, D T4 Class I, Zone 2, Group IIC
Standards and regulations	Air clearances and creepage distances Standards/regulations: DINÃENÃ50178
Mounting	Mounting type: DIN rail mounting Assembly instructions: No end clamp Mounting position: vertical, horizontal
