Sensor/actuator cable, 8-position halogen-free, shielded, free cable end, on Socket straight M12, coding: A, cable length: 10 m

End cover, width: 2.2 mm, height: 64.5 mm, color: gray

End cover, width: 5 mm, height: 62 mm, color: gray

Sensor/actuator cable, 3-position halogen-free, free cable end, on Socket angled M8, coding: A, cable length: 10 m

Continuous plug-in bridge, length: 500 mm, color: red

Distribution block, Basic terminal block with supply, nom. voltage: 450 V, nominal current: 24 A, number of connections: 19, connection method: Push-in connection, Load contact, cross section: 0.14 mm²-4 mm², Push-in connection, Line contact, Rated cross section: 6 mm², cross section: 0.5 mm²-10 mm², mounting type: Free-hanging, color: green/yellow

PCB terminal block, nominal current: 6 A, rated voltage (III/2): 160 V, nominal cross section: 0.5 mm², number of potentials: 9, number of rows: 1, number of positions per row: 9, product range: MPT 0,5, pitch: 2.54 mm, connection method: Screw connection with tension sleeve, screw head form: L Slotted, mounting: Wave soldering, conductor/PCB connection direction: 0°, color: green, Pin layout: Linear pinning, Solder pin [P]: 3.5 mm, number of solder pins per potential: 1, type of packaging: packed in cardboard

Plug, nom. voltage: 500 V, nominal current: 17.5 A, number of connections: 3, number of positions: 3, connection method: Push-in connection, 1 level, Rated cross section: 1.5 mm², cross section: 0.14 mm²-1.5 mm², mounting type: Plug-in mounting, color: gray

Disconnect terminal block, Current and voltage are determined by the plug used., nom. voltage:400 V, nominal current:20 A, 1 level, connection method: Spring-cage connection, Rated cross section:2.5 mm², cross section:0.08 mm²-4 mm², mounting: NS 35/7,5, NS35/15, color:gray

Distributor box, application: Standard, connection method: M12-SPEEDCON-socket Plastic, number of slots: 4, number of positions: 5, coding: A, slot assignment: Double, status display: Yes, pnp; master cable connection: Pluggable screw connection 180°, shielding: no

Connector, Universal, 5-position, Plug straight M12, coding: A, Screw connection, knurl material: Stainless steel 1.4404, cable gland Pg9, external cable diameter 6 mm ... 8 mm

End cover, width: 2.2 mm, height: 45 mm, color: gray

High-current terminal block, nom. voltage: 1000 V, nominal current: 150 A, number of connections: 2, number of positions: 1, connection method: Screw connection, Rated cross section: 50 mm², cross section: 16 mm²-70 mm², mounting type: NS 35/7,5, NS35/15, NS32, NS 35/15-2,3, color: gray

Ground terminal, When aligning with a feed-through terminal block with the same shape, an end cover must be interposed with insulation voltages of > 690 V, number of connections: 2, number of positions: 1, connection method: Screw connection, cross section: 0.2 mm²-4 mm², mounting: PE foot with mounting screw, M2.5, mounting type: NS 35/7,5, NS35/15, NS32, color: green-yellow

Feed-through terminal block, nom. voltage: 800 V, nominal current: 24 A, number of connections: 2, connection method: Spring-cage connection, Rated cross section: 2.5 mm², cross section: 0.08 mm²-4 mm², mounting type: NS 35/7,5, NS35/15, color: blue

Ground terminal, number of connections: 4, connection method: Spring-cage connection, 1 level, cross section: 0.08 mm²-4 mm², mounting type: NS 35/7,5, NS35/15, color: green-yellow

Sensor/actuator cable, 4-position, Plug straight M12, coding: A, connected with unwired, on Socket straight M12, coding: A, cable length: 10 m

Knife-disconnect terminal block, nom. voltage:400 V, nominal current:20 A, connection method: Push-in connection, Rated cross section:2.5 mm², cross section:0.14 mm²-4 mm², mounting: NS 35/7,5, NS35/15, color:gray

Network cable, PROFINET CAT5 (100 Mbps), EtherCAT^® CAT5 (100 Mbps), 4-position, shielded (Advanced Shielding Technology), Plug straight M12, coding: D / IP67, on Socket straight M12, coding: D / IP67, cable length: 2 m
