0830757 PHOENIX CONTACT -

UCT6M-TM 6 - Marker for terminal blocks

Marker for terminal blocks, for marking ABB terminal blocks from the SNK series, Sheet, white, unlabeled, can be labeled with: THERMOMARK CARD, THERMOMARK CARD 2.0, THERMOMARK PRIME, BLUEMARKID, BLUEMARKIDCOLOR, TOPMARK LASER, TOPMARKNEO, mounting type: snapped, for terminal block width: 6 mm, lettering field size: 4.85x11.3mm, Number of individual labels: 50

Cod. Articolo: 0830757 copia - copy

Cod. Fornitore: 0830757 copia - copy

PHOENIX CONTACT

Notes	General: Can be labeled via thermal transfer
Product properties	Product type: Terminal marking Pitch: 6 mm Type: high Area of application: Terminal blocks: ABB series SNK Marking Number of individual labels: 50 Number of individual labels per row: 10 Identification technology: Thermal transfer for sheets and cards
Dimensions	Width: 5.45 mm Height: 2.7 mm Length: 11.9 mm Pitch: 6 mm
Material specifications	RoHS compliant: yes Color: white Material: PC Flammability rating according to UL 94: V0 Relative insulation material temperature index (Elec., UL 746 B): 130°C Fire protection for rail vehicles (DIN EN 45545-2) R22: HL 1 - HL 3 Fire protection for rail vehicles (DIN EN 45545-2) R23: HL 1 - HL 3 Fire protection for rail vehicles (DIN EN 45545-2) R24: HL 1 - HL 3 Components: free from silicone, halogen, and cadmium
Environmental and real-life conditions	Test for substances that would hinder coating with paint or varnish Result: Test passed UV resistance Specification: ISOÃ4892-2:2013-03 (following) Result: Test passed Test duration: 96 h Wipe resistance of inscriptions Specification: DINÃENÃ61010-1 (VDEÃ0411-1):2011-07 DINÃENÃ62208 (VDEÃ0660-511):2012-06 (in parts) Testing in a condensation changing climate in the presence of sulfur dioxide Specification: DINÃ50018:2013-05 Result: Test passed Climate level: AHT 1.0 S Cycles: 2 Salt spray test Specification: DINÃENÃ60068-2-11:2000-02 Result: Test passed Ambient conditions Ambient temperature (operation): -40°C ... 120°C Recommended storage conditions: 23Ã°C/50Ã% relative humidity. Storage in a dry and dark place in the original packaging is recommended. Recommended ambient temperature (storage/transport): 23°C Recommended humidity (storage/transport): 50 %
Standards and regulations	Wipe resistance: DINÃENÃ61010-1 (VDEÃ0411-1)
Mounting	Mounting type: snapped
