0831654 PHOENIX CONTACT -

LS-EMSP-V4A (50X15) - Device marker

Device marker, Stainless steel label, silver, unlabeled, can be labeled with: TOPMARKNEO, TOPMARK LASER, mounting type: screw, rivet, lettering field size: 50x15mm, Number of individual labels: 16

Cod. Articolo: 0831654 copia - copy

Cod. Fornitore: 0831654 copia - copy

PHOENIX CONTACT

Product properties	Product type: Device marking Type: Laser sheet Marking Number of individual labels: 16 Identification technology: Direct laser marking
Mounting	Mounting type: screw, rivet
Material specifications	RoHS compliant: yes Color: silver Material: V4A (1.4404; AISI 316L) Components: free from silicone, halogen, and cadmium
Environmental and real-life conditions	Test for substances that would hinder coating with paint or varnish Result: Test passed Scratch test for the determining scratch resistance Specification: DINÃENÃISOÃ1518-1:2019-10 (following) Tesafilm test Specification: DINÃENÃISOÃ2409:2013 (following) Result: Test passed UV resistance Specification: ISOÃ4892-2:2013-03 (following) IEC 60068-2-2:2007-07 Result: Test passed Test duration: 96 h Duration: 240Ãh Temperature for testing: 350°C Temperature resistance Specification: ANSI/ULÃ969-2018:03 (following) Test duration: 240 h Rating 225Ã°C (250Ã°C): Test passed Wipe resistance of inscriptions Specification: DINÃENÃ61010-1 (VDEÃ0411-1):2011-07 DINÃENÃ62208 (VDEÃ0660-511):2012-06 (in parts) ISOÃ175:2010 (following) Test duration: 168 h IRM 901: Test passed IRM 902: Test passed Testing in a condensation changing climate in the presence of sulfur dioxide Specification: DINÃ50018:2013-05 (following) Result: Test passed Climate level: AHT 1.0 S Cycles: 2 Salt spray test Specification: DINÃENÃ60068-2-11:2000-02 Result: Test passed Test duration: 96 h Salt spray testÃ¢Ã¢¬Ã¢¹ Specification: ISOÃ9227:2017-03 Result: Test passed Test duration: 336 h Ambient conditions Ambient temperature (operation): -80°C ... 350°C Recommended storage conditions: 23Ã°C/50Ã% relative humidity. Storage in a dry and dark place in the original packaging is recommended. Recommended ambient temperature (storage/transport): 23°C Recommended humidity (storage/transport): 50 % Shelf life: 24Ãmonths
Dimensions	Width: 59.7 mm Length: 14.8 mm Hole diameter: 3.20 mm Material strength: 0.50 mm
Standards and regulations	Wipe resistance: DINÃENÃ61010-1 (VDEÃ0411-1)
