| Notes | General: If the fuse is defective, the downstream circuit is not off load |
| Product properties | Product type: Fuse |
| Electrical properties | Nominal current IN: 6.3 A Fuse: G / 5 x 20 / 5 x 25 / 5 x 30 LED voltage range: 15 V ... 30 V |
| Input data | LED voltage range: 15 V ... 30 V |
| Connection data | Nominal current: 6.3 A Nominal voltage: 400 V |
| Dimensions | Width: 9.9 mm Height: 45.4 mm |
| Material specifications | Color: black Flammability rating according to UL 94: V2 Insulating material group: CTI 600 Insulating material: PA Static insulating material application in cold: -60°C Temperature index of insulation material (DIN EN 60216-1 (VDE 0304-21)): 130°C Relative insulation material temperature index (Elec., UL 746 B): 130°C Fire protection for rail vehicles (DIN EN 45545-2) R22: HL 1 - HL 3 Fire protection for rail vehicles (DIN EN 45545-2) R23: HL 1 - HL 3 Fire protection for rail vehicles (DIN EN 45545-2) R24: HL 1 - HL 3 Fire protection for rail vehicles (DIN EN 45545-2) R26: HL 1 - HL 3 Calorimetric heat release NFPA 130 (ASTM E 1354): 28 MJ/kg Surface flammability NFPA 130 (ASTM E 162): passed Specific optical density of smoke NFPA 130 (ASTM E 662): passed Smoke gas toxicity NFPA 130 (SMP 800C): passed |
| Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -60°C ... 105°C (max. short-term operating temperature RTI Elec.) Ambient temperature (storage/transport): -25°C ... 60°C (for a short time, not exceeding 24Ãh, -60ðC to +70ðC) Ambient temperature (assembly): -5°C ... 70°C Ambient temperature (actuation): -5°C ... 70°C Permissible humidity (storage/transport): 30 % ... 70 % |
