| Product properties | Product type: Power cable Application: Power supply Number of positions: 3 No. of cable outlets: 1 Shielded: no Coding: S Insulation characteristics Overvoltage category: III Degree of pollution: 3 |
| Material specifications | Flammability rating according to UL 94: V0 Material of grip body: PP Contact material: CuZn Contact surface material: Ni/Au Contact carrier material: PA Material for screw connection: Zinc die-cast, nickel-plated |
| Electrical properties | Insulation resistance: ââ°¥ 100 Mé Nominal voltage UN: 690 V AC Nominal current IN: 16 A |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: > 100 |
| Connector | Connection 1 Type: Plug straight M12 Coding type: S (Power) Connection 2 Type: Socket straight M12 Coding type: S (Power) |
| Cable/line | Cable length: 8 m PVC black [PVC] Dimensional drawing: https://caas.phoenixcontact.com/caas/v1/stable/media/9248/full/b1500?format=jpg Cable weight: 80 kg/km UL AWM Style: 2517 (105 °C / 300 V) Number of positions: 3 Shielded: no Cable type: PVC black [PVC] Conductor cross section: 3x 1.5 mm² Wire diameter incl. insulation: 2.4 mm ñ0.1 mm External cable diameter: 6.80 mm ñ0.2 mm Outer sheath, material: PVC External sheath, color: black Conductor material: Bare Cu litz wires Material wire insulation: PVC Single wire, color: black 1, black 2, green/yellow Overall twist: 3 wires, twisted Max. conductor resistance: ââ°¤ 13.3 é/km (at 20 °C) Insulation resistance: ââ°¥ 10 Mé*km (at 20 °C) Nominal voltage, cable: 300 V AC Test voltage: 2000 V AC Minimum bending radius, fixed installation: 5 x D Minimum bending radius, flexible installation: 12 x D Smallest bending radius, fixed installation: 34 mm Smallest bending radius, movable installation: 82 mm Flame resistance: according to IEC 60332-1 According to DIN EN 60332-1-2 According to VW-1 According to FT1 Ambient temperature (operation): -40 °C ... 90 °C (cable, fixed installation) -5 °C ... 90 °C (Cable, flexible installation) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP65 IP67 (without preloading, as additional test in accordance with IEC 60529) Ambient temperature (operation): -25 °C ... 85 °C (Plug / socket) |
| Standards and regulations | Standard designation: M12 connector Standards/specifications: IEC 61076-2-111 |
