| Product properties | Type: RJ45 Product type: Female insert Sensor type: Ethernet Number of positions: 8 Connection profile: RJ45 Number of slots: 2 Cable outlet: straight Insulation characteristics Overvoltage category: III Degree of pollution: 2 |
| Electrical properties | Rated voltage (III/3): 72 V (DC) Rated surge voltage: 0.8 kV Rated current: 1 A (at 60ðC) Max. operating voltage Umax: 72 VÃDC Frequency range: 500 MHz Insulation resistance: ââ°¥ 500 Mé Nominal current IN: 0.5 A Contact resistance: 200 mé (Trunk in to trunk out) Transmission characteristics (category): CAT6A |
| Connection data | Connection technology Connection method: Coupling |
| Material specifications | Flammability rating according to UL 94: V0 Housing surface material: metal-plated Contact material: Spring steel Contact surface material: Gold Housing material: Metal |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 750 (IEC 60603-7) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -25°C ... 70°C Ambient temperature (storage/transport): 60°C |
| Standards and regulations | Standards/specifications: IEC 60603-7 DINÃENÃ50173-1 ISO/IEC 11801-Am.1 IEC 60068-2 |
| Mounting | Mounting type: Snap in Connection method: Coupling |
