| Notes | General: For integration into DIN rail adapter NBC-PP-G1PGY |
| Product properties | Type: SC Product type: Female insert Number of positions: 2 Connection profile: SCRJ No. of cable outlets: 2 Number of slots: 1 Protective cover: yes Cable outlet: straight Insulation characteristics Overvoltage category: III Degree of pollution: 2 |
| Electrical properties | Rated surge voltage: 0.8 kV Nominal current IN: 0.5 A Transmission medium: FO |
| Connection data | Connection technology Connection method: Coupling |
| Material specifications | Color of the housing part: green Flammability rating according to UL 94: V0 Ferrule material: Zirconia ceramics Contact material: Copper alloy Housing material: Plastic |
| Cable/line | Cable type: Fiberglass External sheath, color: silver-colored Tensile strength short-term/long-term: 40 N Resistance to oil: no FO cable Number of fibers: 2 Attenuation: ââ°¤ 0.2 dB |
| Mechanical properties | Tensile strength short-term/long-term: 40 N Mechanical data Insertion/withdrawal cycles: ââ°¥ 500 Extraction force per signal contact: ââ°¥ 70 N |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -10°C ... 70°C Resistance to UV radiation: no Resistance to oil: no |
| Standards and regulations | Resistance to UV radiation: no Resistance to oil: no |
| Mounting | Mounting type: Snap in Connection method: Coupling |
