| Product properties | Product type: Power cable Application: Power supply Number of positions: 4 No. of cable outlets: 1 Coding: S Insulation characteristics Overvoltage category: III Degree of pollution: 3 |
| Material specifications | Flammability rating according to UL 94: V0 Material of grip body: PP Contact material: CuZn Contact surface material: Ni/Au Contact carrier material: PA Material for screw connection: Zinc die-cast, nickel-plated |
| Electrical properties | Insulation resistance: ââ°¥ 100 Mé Nominal voltage UN: 690 V AC Nominal current IN: 12 A |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: > 100 |
| Connector | Connection 1 Type: free cable end Connection 2 Type: Socket straight M12 Coding type: S (Power) |
| Cable/line | Cable length: 0.2 m PUR halogen-free black [PUR] Cable weight: 92 kg/km UL AWM Style: 80 °C/1000 V Number of positions: 4 Shielded: no Cable type: PUR halogen-free black [PUR] Conductor cross section: 4x 1.5 mm² Wire diameter incl. insulation: 2.35 mm ñ0.05 mm External cable diameter: 7.40 mm ñ0.25 mm Outer sheath, material: PUR External sheath, color: black-gray RAL 7021 Conductor material: Bare Cu litz wires Material wire insulation: PP Single wire, color: black 1, black 2, black 3, green/yellow Thickness, insulation: ââ°¥ 0.31 mm Thickness, outer sheath: approx. 0.85 mm Overall twist: 4 wires, twisted Max. conductor resistance: ââ°¤ 14.1 é/km (at 20 °C) Insulation resistance: ââ°¥ 1 Gé*km (at 20 °C) Nominal voltage, cable: ââ°¤ 1000 V AC Test voltage: ââ°¥ 10000 V AC (Spark test) Minimum bending radius, fixed installation: 5 x D Minimum bending radius, flexible installation: 10 x D Smallest bending radius, fixed installation: 37 mm Smallest bending radius, movable installation: 74 mm Dynamic load capacity (bending): Max. bending cycles: 4000000, Bending radius: 10 x D, Traversing path: 10 m, Traversing rate: 3 m/s, Acceleration: 10 m/s² Halogen-free: in accordance with DIN VDE 0472 part 815 in accordance with DIN EN 50267-2-1 Flame resistance: According to UL 758/1581 (Cable Flame) in accordance with UL 758/1581 FT2 according to DIN EN 60332-2-2 Resistance to oil: according to DIN EN 60811-404, 168 h at 100 °C according to UL 758, 168 h at 60 °C Other resistance: Hydrolysis and microbe resistant as per VDE 0282 section 10 Low adhesion abrasion-resistant Resistant to salt water Ambient temperature (operation): -50 °C ... 85 °C (cable, fixed installation) -30 °C ... 85 °C (Cable, flexible installation) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP65 IP67 (without preloading, as additional test in accordance with IEC 60529) Ambient temperature (operation): -25 °C ... 85 °C (Plug / socket) |
| Standards and regulations | Standard designation: M12 connector Standards/specifications: IEC 61076-2-111 |
