1085902 PHOENIX CONTACT -

SAC-5P- 5,0-186/M12FS - Sensor/actuator cable

Sensor/actuator cable, 5-position, PUR, black-gray RAL 7021, free cable end, on Socket straight M12, coding: A, cable length: 5 m

Cod. Articolo: 1085902 copia - copy

Cod. Fornitore: 1085902 copia - copy

PHOENIX CONTACT

Product properties	Product type: Sensor/actuator cable Number of positions: 5 No. of cable outlets: 1 Shielded: no Coding: A Insulation characteristics Overvoltage category: II Degree of pollution: 3
Material specifications	Flammability rating according to UL 94: HB
Electrical properties	Insulation resistance: Ã¢Ã¢°¥ 100 MÃ© Nominal voltage U_N: 48 V AC 60 V DC Nominal current I_N: 4 A
Mechanical properties	Mechanical data Insertion/withdrawal cycles: Ã¢Ã¢°¥ 100
Signaling	Status display: no Status display present: No
Connector	Connection 1 Type: free cable end Connection 2 Type: Socket straight M12 Number of positions: 5 Coding type: A
Cable/line	Cable length: 5 m PUR POWER 0.75 mm² black [186] Dimensional drawing: https://caas.phoenixcontact.com/caas/v1/stable/media/9094/full/b1500?format=jpg Cable weight: 67 kg/km Number of positions: 5 Shielded: no Cable type: PUR POWER 0.75 mm² black [186] Conductor structure signal line: 42x 0.15 mm AWG signal line: 18 Conductor cross section: 5x 0.75 mm² (power line) Wire diameter incl. insulation: 1.7 mm Ã±0.05 mm External cable diameter: 6.30 mm Ã±0.2 mm Outer sheath, material: PUR External sheath, color: black-gray RAL 7021 Conductor material: Bare Cu litz wires Material wire insulation: PVC Single wire, color: brown, white, blue, black, gray Thickness, insulation: Ã¢Ã¢°¥ 0.23 mm (Core insulation) Ã¢Ã¢°¥ 0.76 mm (Outer cable sheath) Overall twist: 5 wires around filler to the core Max. conductor resistance: max. 26 Ã©/km (at 20 °C) Insulation resistance: Ã¢Ã¢°¥ 1 MÃ©*km (at 20 °C) Nominal voltage, cable: Ã¢Ã¢°¤ 300 V Test voltage: Ã¢Ã¢°¥ 3000 V Smallest bending radius, movable installation: 63 mm Dynamic load capacity (bending): Max. bending cycles: 2000000, Bending radius: 63 mm, Traversing path: 5 m, Traversing rate: 3 m/s, Acceleration: 5 m/s² Flame resistance: in accordance with DIN UL-Style 20549 Resistance to oil: in accordance with DIN EN 60811-2-1 Ambient temperature (operation): -25 °C ... 80 °C (cable, fixed installation) -5 °C ... 80 °C (Cable, flexible installation)
Environmental and real-life conditions	Ambient conditions Degree of protection: IP65 IP68 Ambient temperature (operation): -25 °C ... 90 °C (Plug / socket) -25 °C ... 80 °C (cable, fixed installation) -5 °C ... 80 °C (Cable, flexible installation)
