1088171 PHOENIX CONTACT -

Notes	General: Sufficient strain relief at the connection point can prevent premature stress and wear. Utilize tie down accessories to eliminate bending and dynamic loads on the connector.
Product properties	Product type: M8/M12 adapters Number of positions: 5 Coding: A Insulation characteristics Overvoltage category: II Degree of pollution: 3
Electrical properties	Nominal voltage U_N: 48 VÃAC 60 VÃDC Nominal current I_N: 4 A
Material specifications	Flammability rating according to UL 94: V0 Seal material: Viton Material of grip body: GF nylon Contact material: CuSn Contact surface material: Ni/Au M12, Ni/Sn DT Contact carrier material: GF nylon Material for screw connection: Nickel-plated brass
Connector	Connection 1 Type: Plug straight DEUTSCH DT04-6P Number of positions: 5 Connection 2 Type: Socket straight M12 Number of positions: 5 Coding type: A
Mechanical properties	Mechanical data Insertion/withdrawal cycles: Ã¢Ã¢°¥ 100
Environmental and real-life conditions	Ambient conditions Degree of protection: IP67 IP69K Ambient temperature (operation): -40°C ... 105°C
Approvals	National Marine Electronics Association Certificate: approved
Standards and regulations	Standard designation: M12 connector Standards/specifications: IEC 61076-2-101 SAE J2030
