| Product properties | Product type: Conductor marking Type: Label Marking Number of individual labels: 165 Number of individual labels per row: 1 Identification technology: Thermal transfer |
| Dimensions | Width: 36.5 mm Length: 24 mm External dimensions Outside diameter: to 7.5 mm |
| Material specifications | RoHS compliant: yes Adhesive: Acrylic Color: white/black Material: Vinyl polymer Components: Free from silicone and cadmium |
| Cable/line | External cable diameter: 4 mm ... 7.5 mm |
| Environmental and real-life conditions | Test for substances that would hinder coating with paint or varnish Result: Test passed UV resistance Specification: ISOÃ4892-2:2013-03 (following) Result: Test passed Test duration: 96 h Wipe resistance of inscriptions Specification: DINÃENÃ61010-1 (VDEÃ0411-1):2011-07 DINÃENÃ62208 (VDEÃ0660-511):2012-06 (in parts) Testing in a condensation changing climate in the presence of sulfur dioxide Specification: DINÃ50018:2013-05 Result: Test passed Climate level: AHT 1.0 S Cycles: 2 Salt spray test Specification: DINÃENÃ60068-2-11:2000-02 Result: Test passed Ambient conditions Ambient temperature (operation): -40°C ... 80°C Recommended storage conditions: 21ðC / 50Ã% relative humidity. Storage in a dry and dark place in the original packaging is recommended. Recommended ambient temperature (storage/transport): 21°C Recommended humidity (storage/transport): 50 % Shelf life: 6Ãmonths |
| Standards and regulations | Wipe resistance: DINÃENÃ61010-1 (VDEÃ0411-1) |
| Mounting | Mounting type: adhesive |
