1139999 PHOENIX CONTACT -

AXC F XT EXP - PLC extension module

Left-alignable PCIe extension interface, for connection to a compatible modular controller from the PLCnext Control range.

Cod. Articolo: 1139999 copia - copy

Cod. Fornitore: 1139999 copia - copy

PHOENIX CONTACT

Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/49825de02f474841a8b8f4b2e5e94cef/-S204x204-FJPG Width: 35 mm Height: 126 mm Depth: 54 mm Note on dimensions: The depth applies when a THÃ35-7.5 DIN rail is used (in accordance with ENÃ60715).
Product properties	Type: modular Product type: I/O component Product family: PLCnext Control Extension
Electrical properties	Potentials: Supply of the logic voltage U Supply voltage: 24 VÃDC Supply voltage range: 19.2 VÃDC ... 30 VÃDC (including all tolerances, including ripple) Current draw: max. 80 mA typ. 80 mA Protective circuit: Reverse polarity protection; Polarity protection diode Transient protection; Suppressor diode
Connection data	Connection technology Connection name: AxiolineÃF connector Conductor connection Connection method: Push-in connection Conductor cross section rigid: 0.2 mm² ... 1.5 mm² Conductor cross section flexible: 0.2 mm² ... 1.5 mm² Conductor cross section AWG: 24 ... 16 Stripping length: 8 mm AxiolineÃF connector Connection method: Push-in connection Conductor cross section, rigid: 0.2 mm² ... 1.5 mm² Conductor cross section, flexible: 0.2 mm² ... 1.5 mm² Conductor cross section AWG: 24 ... 16 Stripping length: 8 mm
Environmental and real-life conditions	Ambient conditions Ambient temperature (operation): -25°C ... 60°C up to 2000Ãm above mean sea level (observe derating) Degree of protection: IP20 Air pressure (operation): 70 kPa ... 106 kPa (up to 3000Ãm above sea level) Permissible humidity (operation): 5 % ... 95 % (according to DINÃENÃ61131-2)
Standards and regulations	Protection class: III (IEC 61140, ENÃ61140, VDEÃ0140-1)
Approvals	ATEX Identification: Ã¯Ã II 3 G Ex ec IIC T4 Gc Certificate: TÃÃVÃ20ÃATEXÃ8618ÃX UKEX Identification: Ã¯Ã II 3 G Ex ec IIC T4 Gc Certificate: PxCIMA23UKEX1139999X IECEx Identification: Ex ec IIC T4 Gc Certificate: IECExÃTURÃ20.0098X
Mounting	Mounting type: DIN rail mounting
