1141311 PHOENIX CONTACT -

EG 22,5-GMF/PC KMGY - Mounting base housing

Component housing, Lower housing part with metal foot catch, without vents, width: 22.5 mm, height: 75 mm, color: light grey (7035), cross connection: without bus connector, number of positions cross connector: not relevant

Cod. Articolo: 1141311 copia - copy

Cod. Fornitore: 1141311 copia - copy

PHOENIX CONTACT

Product properties	Product type: Enclosure bottom part Product family: EG G PC Number of positions: 8 Type: Lower housing part with metal foot catch Housing type: Component housing Ventilation openings present: no Housing series: EG
Dimensions	Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/fdd7f57abcbd3549ae1e3573c4fc7dee/-S204x204-FJPG Width: 22.5 mm Height: 75 mm PCB design PCB thickness: 1.4 mm ... 1.8 mm
Material specifications	Color: light grey (7035) Flammability rating according to UL 94: V0 Surface characteristics: untreated Housing material: Polycarbonate
Environmental and real-life conditions	Ambient conditions Degree of protection: IP20 Max. IP code to attain: IP20 Ambient temperature (operation): -40°C ... 105°C (depending on power dissipation) Ambient temperature (storage/transport): -40°C ... 70°C Ambient temperature (assembly): -5°C ... 100°C
PCB data	Thickness of the PCB: 1.4 mm ... 1.8 mm
Mounting	Mounting type: DIN rail mounting Mounting position: Vertical (horizontal DIN rail)
