| Product properties | Type: SC Product type: Female insert Sensor type: Ethernet Number of positions: 2 Connection profile: SC Number of slots: 2 Cable outlet: straight Insulation characteristics Overvoltage category: III Degree of pollution: 2 |
| Electrical properties | Rated surge voltage: 0.8 kV Attenuation: ââ°¤ 0.2 dB Insulation resistance: ââ°¥ 500 Mé Nominal current IN: 0.5 A Transmission medium: FO |
| Connection data | Connection technology Connection method: Coupling |
| Dimensions | Width: 34.7 mm Height: 9.4 mm Length: 27.4 mm Mechanical characteristics Ferrule diameter: 2.50 mm |
| Material specifications | Color: beige Color of the housing part: beige Flammability rating according to UL 94: V0 Contact material: Copper alloy Housing material: Plastic |
| Cable/line | Cable type: Fiberglass External sheath, color: beige Tensile strength short-term/long-term: 40 N Flame resistance: yes FO cable Number of fibers: 2 Fiber: 50/125Ãõm Fiber type: Multimode Attenuation: ââ°¤ 0.2 dB |
| Mechanical properties | Tensile strength short-term/long-term: 40 N |
| Characteristics | Attenuation: ââ°¤ 0.2 dB |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -20°C ... 70°C Ambient temperature (storage/transport): -40°C ... 85°C Ambient temperature (assembly): 0°C ... 50°C Resistance to UV radiation: no |
| Standards and regulations | Resistance to UV radiation: no Flame resistance: yes |
| Mounting | Connection method: Coupling |
