| Product properties | Product type: Female insert Number of positions: 2 Connection profile: B-FOC (STî) Number of slots: 2 Cable outlet: straight Insulation characteristics Overvoltage category: III Degree of pollution: 2 |
| Electrical properties | Rated surge voltage: 0.8 kV Nominal current IN: 0.5 A Transmission medium: FO |
| Connection data | Connection technology Connection method: Coupling |
| Dimensions | Width: 35 mm Height: 9.4 mm Length: 28.7 mm Mechanical characteristics Ferrule diameter: 2.50 mm |
| Material specifications | Color: silver/matt Color of the housing part: silver Flammability rating according to UL 94: V0 Housing surface material: metal-plated Contact surface material: Gold Housing material: Metal |
| Cable/line | Cable type: Fiberglass External sheath, color: silver-colored Tensile strength short-term/long-term: 40 N Halogen-free: yes Resistance to oil: yes Flame resistance: yes FO cable Number of fibers: 2 Fiber: 9/125Ãõm Fiber type: Singlemode Attenuation: ââ°¤ 0.35 dB |
| Mechanical properties | Tensile strength short-term/long-term: 40 N |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -25°C ... 70°C Ambient temperature (storage/transport): -40°C ... 85°C Ambient temperature (assembly): -5°C ... 55°C Resistance to UV radiation: yes Resistance to oil: yes |
| Standards and regulations | Resistance to UV radiation: yes Flame resistance: yes Resistance to oil: yes |
| Mounting | Connection method: Coupling |
