| Product properties | Type: LC Product type: Fiber optic connector (cable side) Number of positions: 12 Number of slots: 12 Cable outlet: straight |
| Electrical properties | Attenuation: ââ°¤ 0.3 dB (1300Ãnm) Transmission medium: FO |
| Dimensions | Width: 5.5 mm Height: 9.7 mm Length: 2500 mm Mechanical characteristics Ferrule diameter: 1.25 mm |
| Material specifications | Color: beige Color of the housing part: beige Flammability rating according to UL 94: V0 Ferrule material: Zirconia ceramics Material of grip body: beige Outer sheath, material: LSZH |
| Connector | Connection 1 Type: Plug LC Degree of protection: IP20 Connection 2 Type: free cable end free cable end Degree of protection: IP20 |
| Cable/line | Cable length: 2.50 m Cable type: Optical wire 900Ãõm Cable structure: semi-loose compact wires (STB) Outer sheath, material: LSZH Single wire, material: LSZH Wire diameter: 900 mm Individual wire diameter: 900 õm Tensile strength short-term/long-term: 10 N Whip length: 2500 mm Halogen-free: yes Resistance to oil: no Flame resistance: yes FO cable Number of fibers: 12 Fiber: 62.5/125Ãõm Fiber type: Multimode Attenuation: ââ°¤ 0.3 dB Return Loss: ââ°¥ 35 dB Transmission medium: Multi-mode fiberglass |
| Mechanical properties | Tensile strength short-term/long-term: 10 N Mechanical data Insertion/withdrawal cycles: > 500 Smallest bending radius: 30 mm |
| Characteristics | Attenuation: ââ°¤ 0.3 dB (1300Ãnm) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -20°C ... 70°C Ambient temperature (storage/transport): -40°C ... 85°C Ambient temperature (assembly): 0°C ... 50°C Resistance to oil: no |
| Standards and regulations | Flame resistance: yes Resistance to oil: no |
| Mounting | Connection method: LC |
