1261656 PHOENIX CONTACT -

FPM 17.3 69K SP - Monitor

Hygiene monitor with 43.9 cm/17.3" TFT display (capacitive multi-touchscreen), 1920 x 1080 pixels (Full HD) in all-around closed stainless-steel housing without screws or sharp edges. With shatter protection film.

Cod. Articolo: 1261656 copia - copy

Cod. Fornitore: 1261656 copia - copy

PHOENIX CONTACT

Notes	General: Please note that an adapter listed under Ã¢Ã¢¬ÃAccessoriesÃ¢Ã¢¬ is required to operate the device. Utilization restriction EMC note: EMC: class A product, see manufacturer's declaration in the download area
Product properties	Product type: Monitor Computer data Processor: without Operating system: without operating system Cooling: passive RAM: without RAM Data storage system: without data storage Slots: without slots Extras: Shatter protection film Display Display type: 43.9 cm / 17.3"-TFT Screen resolution: 1920ÃxÃ1080ÃPixel(s)Ã(Full HD) Touch technology: projective-capacitive (PCAP) Display lighting type: LED Brightness: 250Ãcd/m² MTBF: 50000Ãh Color spectrum: 16.2 million colors Reading angle left: 89° Reading angle right: 89° Reading angle top: 89° Reading angle bottom: 89°
System properties	User software: without user software
Electrical properties	Supply Supply voltage: 24 VÃDC Supply voltage range: 18 VÃDC ... 30 VÃDC
Interfaces	Interfaces: 3x USB 2.0 1x USB server Optional interfaces: Without optional interface Monitor output: 1x DisplayPort 1x HDMI Network: Without network Bus system: without
Dimensions	External dimensions Width / Height / Depth: 431 mm / 261 mm / 68 mm
Material specifications	Material front plate: Glass (3 mm), hardened and non-reflective Housing material: Stainless steel, fully enclosed
Environmental and real-life conditions	Ambient conditions Degree of protection: IP69K Ambient temperature (operation): 0°C ... 50°C Permissible humidity (operation): 10 % ... 85 % (non-condensing) Permissible humidity (storage/transport): 10 % ... 85 % (non-condensing) Shock: DINÃENÃ60068-2-27 Vibration (operation): DINÃENÃ60068-2-6
Mounting	Mounting type: VESA holder (via adapter) Tube mounting (via adapter) Holder system: VESA MIS-D 100 C
