1269236 PHOENIX CONTACT -

EEM-PM157-SLP - Measuring device

Direct current energy meter with direct measurement up to 1000 V / 650 A, with RS-485 interfaces for the programming software and the DC charging controller, correction of charging cable losses, operating temperature up to +80 °C, certified in accordance with measuring and calibration law

Cod. Articolo: 1269236 copia - copy

Cod. Fornitore: 1269236 copia - copy

PHOENIX CONTACT

Product properties	Product type: Energy meter Data management status Article revision: 00 Insulation characteristics Overvoltage category: III Degree of pollution: 2
Electrical properties	Electric strength: 3521 V (IEC 61851-23, EN 62052-31) Supply Supply voltage range: 19.2 V DC ... 36 V DC
Input data	Measurement Input voltage range: 150 V DC ... 1000 V DC Input current range: 6.5 A ... 650 A 1 % (EN 50470-3) Power consumption: < 5 W < 0.5 W (U_N) < 0.12 W (I_max) Start current I_st: 0.52 A Minimal current I_min: 6.5 A Maximum current I_max: 650 A Transient current I_tr: 13 A Nominal current I_ref: 130 A
Output data	Pulse LED: 1000 imp/kWh
Connection data	Voltage Conductor cross section rigid: 0.75 mm² ... 1.5 mm² Conductor cross section flexible: 0.75 mm² ... 1.5 mm² Conductor cross section AWG: 20 ... 16 Tightening torque: 0.5 Nm ... 0.6 Nm Current Connection method: Screw connection Screw thread: M8 M10 Tightening torque: 17.5 Nm ... 20 Nm
Interfaces	Communication: Communication standard: RS-485 Connection method: RJ12 Transmission speed range: 9600 bps ... 115200 bps Parity: odd, even, none
Dimensions	Width: 107.2 mm Height: 115.6 mm Depth: 66.75 mm
Environmental and real-life conditions	Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -40 °C ... 80 °C Ambient temperature (storage/transport): -40 °C ... 85 °C Altitude: Ã¢Ã¢°¤ 2000 m Max. permissible relative humidity (operation): 97.5 % (non-condensing)
Approvals	CE Certificate: CE-compliant Calibration law Certificate: Conforms to calibration law
Standards and regulations	Standards/specifications: EN 50470-1 EN 50470-3 IEC 62052-41 DIN EN 62052-11 VDE-AR-E 2418-3-100 EN 62053-41 OCMF 1.0 PTB-A 20.1 PTB-A 50.7
Mounting	Mounting type: NS 35 ... Mounting position: Horizontal DIN rail
