| Product properties | Type: USB-A Socket Product type: Data connector (device side) Sensor type: USB 2.0 Number of positions: 4 Type of packaging: Tape and Reel [W] tape width: 32.00 mm [A] coil diameter: 330.00 mm Connection profile: USB-A Number of slots: 1 Shielded: yes Insulation characteristics Overvoltage category: I Degree of pollution: 2 |
| Electrical properties | Rated voltage (III/2): 30 V Rated surge voltage (III/2): 1500 V Rated current: 1.5 A Contact resistance: 30 mé Frequency range: 10 Hz ... 55 Hz Insulation resistance: 1000 Mé Transmission medium: Copper Transmission characteristics (category): USB 2.0 Transmission speed: 480 Mbps Power transmission: 45 W |
| Connection data | Connection technology Connection method: Solder connection |
| Dimensions | Width: 14.5 mm Height: 7.14 mm Length: 14.13 mm Orientation to: 90.00° |
| Material specifications | Color of the housing part: black Flammability rating according to UL 94: V0 Contact material: Copper alloy Contact surface material: Gold over nickel Contact carrier material: LCP Housing material: Metal |
| Cable/line | Test voltage Core/Core: 500 V Test voltage Core/Shield: 500 V Acceleration: 3.1 m/s² Halogen-free: yes |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: > 1500 Insertion force per signal contact: 35.00 N Extraction force per signal contact: < 10 N |
| Environmental and real-life conditions | Test specification Specification: EIA 364-1000 Frequency: 10-55 Hz Sweep speed: 1Ãoctave/min Amplitude: 1.52 mm Test duration: 2 h Contact resistance R1: 30 mé Test specificationââ¬Ã¢¹ Specification: 60068-2-27 Acceleration: 50 g Number of shocks per direction: 18 Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -55°C ... 85°C |
| Mounting | Mounting type: SMD soldering Connection method: Solder connection Processing notes Process: SMD Moisture Sensitive Level: MSL 1 Classification temperature Tc: 260°C Solder cycles in the reflow: 3 |
