| Product properties | Type: USB-A Socket Product type: Data connector (device side) Sensor type: USB 3.0 Number of positions: 9 Type of packaging: Tray Connection profile: USB-A Number of slots: 1 Shielded: yes Insulation characteristics Overvoltage category: I Degree of pollution: 2 |
| Electrical properties | Rated voltage (III/2): 30 V Rated surge voltage (III/2): 1500 V Rated current: 1.8 A Contact resistance: 30 mé Frequency range: 20 Hz ... 500 Hz Insulation resistance: 1000 Mé Transmission medium: Copper Transmission characteristics (category): USB 3.2 Gen 1 Transmission speed: 5 GBit/s Power transmission: 54 W |
| Connection data | Connection technology Connection method: Solder connection |
| Dimensions | Width: 14.4 mm Height: 7.74 mm Length: 16.5 mm Orientation to: 90.00° |
| Material specifications | Color of the housing part: blue Flammability rating according to UL 94: V0 Contact material: Copper alloy Contact surface material: Gold over nickel Contact carrier material: PA 4T Housing material: Metal |
| Cable/line | Test voltage Core/Core: 500 V Test voltage Core/Shield: 500 V Acceleration: 3.1 m/s² Halogen-free: yes |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: > 5000 Insertion force per signal contact: 35.00 N Extraction force per signal contact: < 10 N |
| Environmental and real-life conditions | Test specification Specification: EIA 364-1000 Frequency: 20-500 Hz Sweep speed: 1Ãoctave/min Acceleration: 3.1 m/s² Test duration: 15 min. Contact resistance R1: 30 mé Test specificationââ¬Ã¢¹ Specification: 60068-2-27 Acceleration: 30 g Number of shocks per direction: 18 Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -55°C ... 85°C |
| Mounting | Mounting type: Wave soldering Connection method: Solder connection Processing notes Process: Wave soldering Classification temperature Tc: 260°C |
