1337243 PHOENIX CONTACT -

CUC-SP-J1ST-A/R4LT-THR-LED - RJ45 PCB connectors

RJ45 PCB connectors, degree of protection: IP20, number of positions: 8, 10 Gbps, material: Metal, connection method: THR reflow/THT wave, cable outlet: straight

Cod. Articolo: 1337243 copia - copy

Cod. Fornitore: 1337243 copia - copy

PHOENIX CONTACT

Product properties	Type: RJ45 Socket Product type: Data connector (device side) Number of positions: 8 Type of packaging: Tape and Reel [W] tape width: 44.00 mm [A] coil diameter: 330.00 mm [W2] coil overall dimension: 49.10 mm Housing shield springs: No Connection profile: RJ45 Number of slots: 1 Shielded: yes Cable outlet: straight LED: yes Insulation characteristics Overvoltage category: I Degree of pollution: 2
Electrical properties	Rated voltage (III/2): 72 VÃDC Rated surge voltage: 1.5 kV DC 1 kV DC Rated surge voltage (III/3): 1.5 kV Rated current: 1.5 A Frequency range: 10 Hz ... 500 Hz Insulation resistance: > 500 MÃ© Test voltage: 1 kV DC Test voltage Core/Core: 1 kV DC Test voltage Core/Shield: 1.5 kV DC Transmission medium: Copper Transmission speed: 10 Gbps Power transmission: PoE++
Connection data	Connection technology Connection method: THR reflow/THT wave
Dimensions	Width: 16.8 mm Height: 16.6 mm Length: 16.2 mm Installed height: 13.70 mm Data pin length: 2.00 mm
Material specifications	Material: Au (1,27ÃÃµm/50ÃÃµ") Sn (2.54ÃÃµm/100ÃÃµ") Ni (1,27 Ãµm/50 Ãµ") Ni (1.27ÃÃµm / 50 Ãµ") Stainless steel LCP Flammability rating according to UL 94: V0 Contact material: Phosphor bronze Contact surface material: Gold over nickel Contact carrier material: LCP Housing material: Metal
Cable/line	Test voltage Core/Core: 1 kV DC Test voltage Core/Shield: 1.5 kV DC Halogen-free: yes
Mechanical properties	Mechanical data Insertion/withdrawal cycles: > 750 Insertion force per signal contact: < 20.00 N Extraction force per signal contact: < 20 N
Environmental and real-life conditions	Test specification Frequency: 10-500 Hz Sweep speed: 1Ãoctave/min Amplitude: 0.35 mm Acceleration: 50 m/s² Test duration: 20 s Test specificationÃ¢Ã¢¬Ã¢¹ Specification: IEC60068-2-27 Acceleration: 295 m/s² Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -50°C ... 85°C Ambient temperature (storage/transport): -50°C ... 85°C
Mounting	Mounting type: PCB mounting Connection method: THR reflow/THT wave Processing notes Process: THR Moisture Sensitive Level: MSL 1 Classification temperature T_c: 260°C Solder cycles in the reflow: 3
