| Product properties | Type: RJ45 Socket Product type: Data connector (device side) Number of positions: 8 Type of packaging: Tape and Reel [W] tape width: 56.00 mm [A] coil diameter: 330.00 mm [W2] coil overall dimension: 61.10 mm Housing shield springs: Yes Connection profile: RJ45 Number of slots: 2 Shielded: yes Insulation characteristics Overvoltage category: I Degree of pollution: 2 |
| Electrical properties | Rated voltage (III/2): 72 VÃDC Rated surge voltage: 1.5 kV DC 1 kV DC Rated surge voltage (III/3): 1.5 kV Rated current: 1.5 A Frequency range: 10 Hz ... 500 Hz Insulation resistance: > 500 Mé Test voltage: 1 kV DC Test voltage Core/Core: 1 kV DC Test voltage Core/Shield: 1.5 kV DC Transmission medium: Copper Transmission speed: 10 Gbps Power transmission: PoE++ |
| Connection data | Connection technology Connection method: THR reflow/THT wave |
| Dimensions | Width: 35.5 mm Height: 18.2 mm Length: 15.9 mm Installed height: 13.60 mm Orientation to: 90.00° Data pin length: 2.00 mm |
| Material specifications | Material: Au (1,27Ãõm/50Ãõ") Sn (2.54Ãõm/100Ãõ") Ni (1,27 õm/50 õ") Ni (1.27Ãõm / 50 õ") Stainless steel LCP Flammability rating according to UL 94: V0 Contact material: Phosphor bronze Contact surface material: Gold over nickel Contact carrier material: LCP Housing material: Metal |
| Cable/line | Test voltage Core/Core: 1 kV DC Test voltage Core/Shield: 1.5 kV DC Halogen-free: yes |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: > 750 Insertion force per signal contact: < 20.00 N Extraction force per signal contact: < 20 N |
| Environmental and real-life conditions | Test specification Frequency: 10-500 Hz Sweep speed: 1Ãoctave/min Amplitude: 0.35 mm Acceleration: 50 m/s² Test duration: 20 s Test specificationââ¬Ã¢¹ Specification: IEC60068-2-27 Acceleration: 295 m/s² Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -50°C ... 85°C Ambient temperature (storage/transport): -50°C ... 85°C |
| Mounting | Mounting type: PCB mounting Connection method: THR reflow/THT wave Processing notes Process: THR Moisture Sensitive Level: MSL 1 Classification temperature Tc: 260°C Solder cycles in the reflow: 3 |
