| Product properties | Type: SPE Product type: Data connector (cable side) Sensor type: Single Pair Ethernet Number of positions: 2 Connection profile: SPE Number of slots: 2 Shielded: yes Cable outlet: straight Insulation characteristics Overvoltage category: I Degree of pollution: 2 |
| Electrical properties | Rated current: 2 A Frequency range: 600 MHz Insulation resistance: > 500 Mé Contact resistance: < 20 mé Transmission medium: Copper Transmission characteristics (category): CAT5 Transmission speed: 1 Gbps Power transmission: PoDL |
| Connection data | Connection technology Connection method: IDC fast connection Connection cross section AWG: 26 AWG ... 22 AWG (solid) 26 AWG ... 22 AWG (flexible) Conductor cross section: 0.18 mm² ... 0.45 mm² |
| Interfaces | Transmission speed: 100 Mbps (in accordance with IEEEÃ802.3 bw) 1 Gbps (in accordance with IEEEÃ802.3 bp) 10 Mbps (in accordance with IEEEÃ802.3 cg) |
| Dimensions | Width: 7.5 mm Height: 11.3 mm Length: 32.85 mm |
| Material specifications | Flammability rating according to UL 94: V0 Housing surface material: Nickel Contact material: CuSn Contact surface material: Au Contact carrier material: PC Housing material: Metal |
| Cable/line | External cable diameter (): 3.6 mm ... 5.7 mm Stripping length of the individual wire: 15 mm Test voltage Core/Core: 1000 VÃDC Test voltage Core/Shield: 2250 VÃDC Halogen-free: yes |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: > 750 |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP20 Ambient temperature (operation): -40°C ... 85°C Ambient temperature (storage/transport): -40°C ... 85°C Ambient temperature (assembly): -25°C ... 85°C |
| Mounting | Mounting type: For field assembly Assembly instructions: Max. 4x reconnectable with the same or larger conductor cross-section Connection method: IDC fast connection |
