| Product properties | Type: SPE Product type: Data connector (device side) Sensor type: Single Pair Ethernet Number of positions: 2 Type of packaging: Tape and Reel [W] tape width: 44.00 mm [A] coil diameter: 330.00 mm [W2] coil overall dimension: 38.40 mm Number of slots: 1 Cable outlet: straight Thread type: M12 Insulation characteristics Overvoltage category: II Degree of pollution: 2 |
| Electrical properties | Maximum load current: 4 A Rated surge voltage: 500 V Rated current: 4 A Insulation resistance: min. 1 Té Contact resistance: 20 mé Transmission medium: Copper Transmission characteristics (category): CAT B Transmission speed: 1 Gbps Power transmission: PoDL |
| Output data | Transmission frequency: 600.00 MHz |
| Connection data | Connection technology Connection method: THR solder connection |
| Interfaces | Transmission speed: 1 Gbps1 Gbps |
| Dimensions | Width: 12.4 mm Height: 19.4 mm Length: 13.7 mm Installed height: 21.60 mm Orientation to: 180.00° |
| Material specifications | Color: black Color of the housing part: black Flammability rating according to UL 94: V0 Housing surface material: LCP Contact material: Cu alloy Contact surface material: Au/Ni Housing material: LCP |
| Cable/line | Test voltage Core/Core: 1000 VÃDC Test voltage Core/Shield: 2250 VÃDC Test voltage, cable: 300 V |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: > 100 Insertion force per signal contact: < 30.00 N (in accordance with IEC 63171) Extraction force per signal contact: < 30 N (in accordance with IEC 63171) Smallest bending radius: 21,2 mm |
| Environmental and real-life conditions | Test specification Type of test: Vibration test Specification: IEC 60068-2-6 Frequency: 10-500 Hz Sweep speed: 1Ãoctave/min Amplitude: 0.35 mm Acceleration: 50 m/s² Test duration: 2 h Test specificationââ¬Ã¢¹ Specification: IEC 63171 Corrosive stress: IEC 60512-11-7 Contact resistance R1: 20 mé Test specificationââ¬Ã¢¹Ã¢Ã¢¬Ã¢¹ Type of test: Mechanical service life with corrosion test Specification: DIN EN 60512-9-1 Test specificationââ¬Ã¢¹Ã¢Ã¢¬Ã¢¹Ã¢Ã¢¬Ã¢¹ Type of test: Shock testing Specification: IEC 60068-2-27 Acceleration: 150 m/s² Number of shocks per direction: 2000 Ambient conditions Degree of protection: IP65/IP67 Ambient temperature (operation): -40°C ... 85°C (Harsh environment) Ambient temperature (storage/transport): -40°C ... 85°C (DIN EN 60512-6-3) Resistance to UV radiation: yes |
| Standards and regulations | Resistance to UV radiation: yes |
| Mounting | Mounting type: PCB mounting Connection method: THR solder connection Processing notes Process: Reflow Moisture Sensitive Level: MSL 1 Classification temperature Tc: 260°C Solder cycles in the reflow: 3 |
