| Product properties | Product type: Current transformer |
| Electrical properties | Test voltage: 3 kV (ENÃ61869-1) Rated insulation voltage: 0.72 kV Measuring coil Length of signal cable: 3 m General Converter type: Split-core current transformer |
| Input data | Current transformers Rated power: 0.2 VA Thermal rated short-time current: Ith = 60 * In Thermal rated continuous current: Id = 1.2 * In Rated surge current: Idyn = 2.5 * Ith Rated frequency fn: 50 Hz 60 Hz Primary rated current range: 0 A AC ... 50 A AC (depends on type) Converter type: Split-core current transformer |
| Output data | Signal Designation: Current output Secondary rated current range Isn: 0 A AC ... 1 A AC Surge current limitation factor: FS 10 Accuracy class: 1 |
| Connection data | Secondary connection Connection method: Single wires |
| Dimensions | Item dimensions Width: 73 mm Height: 35 mm Depth: 22 mm Circular conductor Diameter: 13 mm (Inner hole) Signal line Length: 3 m Width: 73 mm Height: 35 mm Depth: 22 mm Primary round conductor (diameter): 13 mm |
| Material specifications | Flammability rating according to UL 94: V0 Housing material: PC |
| Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -40°C ... 65°C Ambient temperature (storage/transport): -45°C ... 80°C Altitude: ââ°¤ 2000 m Permissible humidity (operation): Use only indoors, non-condensing |
| Standards and regulations | Standards/regulations: IEC 61010-1 IEC 61010-2-032 IEC 61869-1 IEC 61869-2 |
