| Product properties | Product type: Sensor/actuator cable Application: Standard Number of positions: 5 No. of cable outlets: 1 Shielded: no Coding: A Insulation characteristics Overvoltage category: II Degree of pollution: 3 |
| Electrical properties | Insulation resistance: ââ°¥ 100 Mé Nominal voltage UN: 48 V AC 60 V DC Nominal current IN: 4 A |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 100 |
| Signaling | Status display: no Status display present: No |
| Connection data | Conductor connection Tightening torque: 0.4 Nm |
| Connector | Connection 1 Type: Plug straight M12 Push Pull Number of positions: 5 Locking type: Push Pull Connection 2 Type: Socket straight M12 Number of positions: 5 Coding type: A |
| Cable/line | Cable length: 0.6 m PUR halogen-free black [PUR] Dimensional drawing: https://caas.phoenixcontact.com/caas/v1/stable/media/9068/full/b1500?format=jpg Shielded: no UL AWM Style: 20549 Cable weight: 33 kg/km Cable type: PUR halogen-free black Cable type (abbreviation): PUR External cable diameter: 4.55 mm ñ0.15 mm Outer sheath, material: PUR External sheath, color: black-gray RAL 7021 Conductor material: Bare Cu litz wires Conductor structure signal line: 42x 0.10 mm AWG signal line: 22 Conductor cross section: 5x 0.34 mm² (Signal line) Material wire insulation: PP Thickness, insulation: approx. 0.50 mm Wire diameter incl. insulation: 1.27 mm 0.05 mm (Signal line) Single wire, color: brown, white, blue, black, green-yellow Nominal voltage, cable: 300 V Test voltage, cable: 3000 V Cable resistance: max. 58 é/km (at 20 °C) Cable insulation resistance: ââ°¥ 16 Gé*km (at 20 °C) Smallest bending radius, fixed installation: 23 mm Smallest bending radius, movable installation: 46 mm Number of bending cycles: 4000000 Bending radius: 50 mm Traversing path: 10 m Traversing rate: 3 m/s Acceleration: 10 m/s² Halogen-free: in accordance with DIN VDE 0472 part 815 Resistance to oil: in accordance with DIN EN 60811-2-1 Flame resistance: in accordance with UL 758/1581 FT2 DIN EN 60332-2-2 (20 s) Other resistance: Highly resistant to acids, alkaline solutions and solvents hydrolysis and microbe resistant Resistant to salt water partly UV-resistant (in accordance with DIN EN ISO 4892-2-A) Special properties: Flexible cable conduit capable Silicone-free Free of substances which would hinder coating with paint or varnish flexible Ambient temperature (operation): -25 °C ... 80 °C (Cable, flexible installation) -40 °C ... 80 °C (cable, fixed installation) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP65 IP67 Ambient temperature (operation): -25 °C ... 85 °C (Plug / socket) |
| Standards and regulations | Standard designation: M12-Push-Pull Standards/specifications: IEC 61076-2-010 |
