| Product properties | Product type: Data cable preassembled Number of positions: 2 No. of cable outlets: 1 Shielded: yes Coding: B Insulation characteristics Overvoltage category: II Degree of pollution: 3 |
| Signaling | Status display: no Status display present: No |
| Electrical properties | Insulation resistance: ââ°¥ 100 Mé Nominal voltage UN: 48 V AC 60 V DC Nominal current IN: 4 A |
| Material specifications | Flammability rating according to UL 94: V0 Seal material: NBR Material of grip body: TPU, hardly inflammable, self-extinguishing Contact material: CuSn Contact surface material: Ni/Au Contact carrier material: PA 6.6 Material for screw connection: Zinc die-cast, nickel-plated |
| Connector | Connection 1 Type: Plug straight M12 Number of positions: 2 Coding type: B (inverse) Connection 2 Type: Socket straight M12 Number of positions: 2 |
| Cable/line | Cable length: 2 m PROFIBUS [910] Dimensional drawing: https://caas.phoenixcontact.com/caas/v1/stable/media/9118/full/b1500?format=jpg Cable weight: 90 kg/km UL AWM Style: 21198 (80 °C/300 V) Number of positions: 2 Shielded: yes Cable type: PROFIBUS [910] Conductor structure: 1x2xAWG24/19 Conductor structure signal line: 19x 0.13 mm AWG signal line: 24 Conductor cross section: 2x 0.25 mm² (Signal line) Wire diameter incl. insulation: 2.55 mm ñ0.07 mm External cable diameter: 7.80 mm ñ0.2 mm Outer sheath, material: PUR External sheath, color: red lilac RAL 4001 Conductor material: Tin-plated Cu litz wires Material, filler: PP Material wire insulation: Foam-Skin PP Single wire, color: red, green Overall twist: 2 cores with 2 fillers to the core Optical shield covering: 85 % Max. conductor resistance: ââ°¤ 78.6 é/km Insulation resistance: ââ°¥ 5 Gé*km Wave impedance: 150 é ñ10 % (3 MHz ... 20 MHz) Cable capacity: nom. 30 pF/m Nominal voltage, cable: 300 V Test voltage Core/Core: 1500 V (50 Hz, 1 min.) Test voltage Core/Shield: 1500.00 V (50 Hz, 1 min.) Smallest bending radius, fixed installation: 40 mm Smallest bending radius, movable installation: 65 mm Dynamic load capacity (bending): Max. bending cycles: 4000000, Bending radius: 65 mm, Traversing path: 4.5 m, Traversing rate: 3 m/s, Acceleration: 3 m/s², Ambient temperature: -20 °C ... 60 °C Max. bending cycles: 5000000, Bending radius: 80 mm, Traversing path: 4.5 m, Traversing rate: 3 m/s, Acceleration: 3 m/s², Ambient temperature: -20 °C ... 60 °C Shield attenuation: ââ°¤ 0.049 dB/m (at 16 MHz) Halogen-free: in accordance with DIN VDE 0472 part 815 according to IEC 60754-1 Flame resistance: UL 1581, Section 1060 and UL 2556, Section 9.3 (FT1) UL 1581, Section 1100 and UL 2556, Section 9.1 (HFT/FT2) IEC 60332-1-2 Other resistance: Low adhesion Ambient temperature (operation): -40 °C ... 80 °C (cable, fixed installation) -30 °C ... 70 °C (Cable, flexible installation) -20 °C ... 60 °C (for installation) -20 °C ... 60 °C (cable, drag chain applications) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP65 IP67 IP68 Ambient temperature (operation): -25 °C ... 90 °C (Plug / socket) -40 °C ... 80 °C (cable, fixed installation) -20 °C ... 80 °C (Cable, flexible installation) |
