1401474 PHOENIX CONTACT -

SAC-3P-10,0-PVC/M 8FS BK VA - Sensor/actuator cable

Sensor/actuator cable, 3-position, PVC, black RAL 9005, free cable end, on Socket straight M8, coding: A, cable length: 10 m

Cod. Articolo: 1401474 copia - copy

Cod. Fornitore: 1401474 copia - copy

PHOENIX CONTACT

Product properties	Product type: Sensor/actuator cable Number of positions: 3 No. of cable outlets: 1 Shielded: no Coding: A Insulation characteristics Overvoltage category: II Degree of pollution: 3
Material specifications	Flammability rating according to UL 94: HB Seal material: NBR Material of grip body: TPU, hardly inflammable, self-extinguishing Contact material: CuSn Contact surface material: Ni/Au Contact carrier material: TPU GF Material for screw connection: Stainless steel
Electrical properties	Insulation resistance: Ã¢Ã¢°¥ 100 MÃ© Nominal voltage U_N: 48 V AC 60 V DC Nominal current I_N: 4 A
Signaling	Status display: no Status display present: No
Connector	Connection 1 Type: free cable end Connection 2 Type: Socket straight M8 Number of positions: 3 Coding type: A
Cable/line	Cable length: 10 m PVC black [PVC] Dimensional drawing: https://caas.phoenixcontact.com/caas/v1/stable/media/8956/full/b1500?format=jpg Cable weight: 29 kg/km Number of positions: 3 Shielded: no Cable type: PVC black [PVC] Conductor structure signal line: 32x 0.10 mm AWG signal line: 24 Conductor cross section: 3x 0.25 mm² (Signal line) Wire diameter incl. insulation: 1.25 mm Ã±0.02 mm External cable diameter: 4.40 mm Ã±0.15 mm Outer sheath, material: PVC External sheath, color: black RAL 9005 Conductor material: Bare Cu litz wires Material wire insulation: PVC Single wire, color: brown, blue, black Thickness, insulation: Ã¢Ã¢°¥ 0.23 mm (Core insulation) Thickness, outer sheath: Ã¢Ã¢°¥ 0.76 mm Overall twist: 3 wires, twisted Max. conductor resistance: max. 78 Ã©/km (at 20 °C) Insulation resistance: Ã¢Ã¢°¥ 100 MÃ©*km (at 20 °C) Nominal voltage, cable: Ã¢Ã¢°¥ 300 V Test voltage: Ã¢Ã¢°¤ 3000 V Flame resistance: As per UL-Style 2464 Ambient temperature (operation): -25 °C ... 80 °C (cable, fixed installation) -5 °C ... 80 °C (Cable, flexible installation)
Environmental and real-life conditions	Ambient conditions Degree of protection: IP65 IP67 IP68 IP69K Ambient temperature (operation): -25 °C ... 90 °C (Plug / socket) -25 °C ... 80 °C (cable, fixed installation) -5 °C ... 80 °C (Cable, flexible installation)
