| Product properties | Product type: Data cable preassembled Sensor type: PROFIBUS Number of positions: 2 Application: Bus system No. of cable outlets: 1 Shielded: yes Coding: B Insulation characteristics Overvoltage category: II Degree of pollution: 3 |
| Interfaces | Bus system: PROFIBUS Signal type/category: PROFIBUS |
| Signaling | Status display: No Status display present: No |
| Electrical properties | Contact resistance: ââ°¤ 5 mé Insulation resistance: ââ°¥ 100 Mé Nominal voltage UN: 48 VÃAC 60 VÃDC Nominal current IN: 4 A Transmission medium: Copper |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 100 |
| Material specifications | Flammability rating according to UL 94: V0 Seal material: NBR Material of grip body: TPU, hardly inflammable, self-extinguishing Contact material: CuSn Contact surface material: Ni/Au Contact carrier material: PA 6.6 Material for screw connection: Stainless steel |
| Connection data | Pin assignment Contact | Color (signal designation) | Contact (optional): 2 (Plug) | GN (A cable) | 2 (Socket) 4 (Plug) | RD (B cable) | 4 (Socket) |
| Connector | Connection 1 Type: Plug straight M12 Number of positions: 2 Coding type: B (inverse) Connection 2 Type: Socket straight M12 Number of positions: 2 Coding type: B |
| Cable/line | Cable length: 1 m PROFIBUSÃ[915] Cable weight: 74 kg/km Number of positions: 2 Shielded: yes Cable type: PROFIBUSÃ[915] Conductor structure: 1x2xAWG24/19 Conductor structure signal line: 19x 0.14 mm AWG signal line: 24 Conductor cross section: 2x 0.25 mm² Wire diameter incl. insulation: 2.56 mm External cable diameter: 8 mm ñ0.4Ãmm Outer sheath, material: PUR External sheath, color: blue Conductor material: Bare Cu litz wires Material wire insulation: Foamed PE Single wire, color: red, green Thickness, outer sheath: approx. 0.8 mm Overall twist: 2 wires, twisted Optical shield covering: 70 % Insulation resistance: ââ°¥ 16 Gé*km Working capacitance: 28 nF (at 1 kHz) Nominal voltage, cable: ââ°¤ 100 V Test voltage Core/Core: 3600 VÃDC Minimum bending radius, flexible installation: 5 x D Max. bending cycles: 3000000 Tensile strength: ââ°¤ 100 N Flame resistance: according to IEC 60332-1 Resistance to oil: Resistant to mineral oils and grease Ambient temperature (operation): -40°C ... 80°C (Cable, flexible installation) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP65 IP67 IP68 IP69K Ambient temperature (operation): -25°C ... 90°C (Plug / socket) |
