1404863 PHOENIX CONTACT -

Product properties	Product type: Data cable preassembled Sensor type: Ethernet Number of positions: 8 Shielded: yes
Interfaces	Signal type/category: Ethernet CAT5, 1 Gbps
Electrical properties	Nominal voltage U_N: 30 VÃAC 30 VÃDC
Cable/line	Cable length: 500 m EthernetÃ[94D] Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/4126776af2f2f646aa88c4da963a2d68/-S204x204-FJPG UL AWM Style: 2464 (80°C/300 V) Number of positions: 8 Shielded: yes Cable type: EthernetÃ[94D] Conductor structure: 4x2xAWG26/7, SF/UTP Signal speed: 0.6 c Conductor structure signal line: 7x 0.16 mm AWG signal line: 26 Conductor cross section: 4x 2x 0.14 mm² Wire diameter incl. insulation: 0.98 mm Ã±0.05 mm External cable diameter: 6.4 mm Ã±0.2Ãmm Outer sheath, material: PVC (reinforced) UV-resistant External sheath, color: black RALÃ9005 Conductor material: Bare Cu litz wires Material wire insulation: PP Single wire, color: white/blue-blue, white/orange-orange, white/green-green, white/brown-brown Thickness, outer sheath: 0.8 mm Twisted pairs: 2 cores to the pair Overall twist: 4 pairs, twisted Optical shield covering: 85 % Max. conductor resistance: < 140 Ã©/km Insulation resistance: Ã¢Ã¢°¥ 5 GÃ©*km Wave impedance: 100 Ã© Ã±15ÃÃ© (at 4 ... 100 MHz) Cable capacity: < 56 nF/km Nominal voltage, cable: 72 VÃDC 300 VÃAC Test voltage Core/Core: 2500 VÃDC (2 s) Test voltage Core/Shield: 2500 VÃDC (2 s) Smallest bending radius, fixed installation: 30 mm Smallest bending radius, movable installation: 60 mm Tensile strength: 80 N Flame resistance: According to VW-1 Resistance to oil: according to IEC 60811-2-1 Other resistance: UV resistant According to ULÃ1581, Section 1200 Ambient temperature (operation): -40°C ... 80°C (cable, fixed installation) Ambient temperature (installation): 0°C ... 50°C
