| Product properties | Product type: Data cable by the meter Sensor type: AS-Interface Number of positions: 2 |
| Electrical properties | Rated voltage (III/3): 32 V Rated surge voltage: 2 kV |
| Interfaces | Signal type/category: AS-Interface |
| Dimensions | Width: 10 mm Height: 4 mm |
| Cable/line | Cable length: 100 m Cable weight: 64 kg/km Number of positions: 2 Shielded: no Conductor structure: 2ÃxÃ1.5Ãmm² Conductor type: Flat cable Conductor structure signal line: 84x 0.15 mm AWG signal line: 16 Conductor cross section: 1.5 mm² Wire diameter incl. insulation: 2.5 mm Outer sheath, material: TPE External sheath, color: lemon yellow RAL 1012 Conductor material: Bare Cu litz wires Material wire insulation: TPE Single wire, color: brown, blue Thickness, insulation: approx. 0.5 mm Max. conductor resistance: ââ°¤ 13.7 é/km Insulation resistance: ââ°¥ 1 Mé*km Nominal voltage, cable: 32 V Test voltage: 2000 V Smallest bending radius, fixed installation: ââ°¥ 6 mm (one-time) Max. bending cycles: 8000000 10000000 Halogen-free: no Flame resistance: ULÃ1581, Sec.Ã1061 (Cable Flame) IEC 60332-1-2 Resistance to oil: ULÃ1581, Sec. 480 (60°C) Other resistance: UV resistant Special properties: UL-Style 2103 CSA-File LL55255-42 Ambient temperature (operation): -40°C ... 105°C (cable, fixed installation) -30°C ... 105°C (Cable, flexible installation) |
| Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -30°C ... 105°C (Flexibly installed) -40°C ... 105°C (fixed routing) Ambient temperature (storage/transport): -40°C ... 105°C Ambient temperature (assembly): -30°C ... 105°C |
