| Product properties | Product type: Ground terminal block Number of connections: 1 Number of rows: 1 Data management status Article revision: 01 |
| Electrical properties | Rated surge voltage: 5 kV Maximum power dissipation for nominal condition: 0.77 W |
| Connection data | Grounding foot: Yes Number of connections per level: 1 Nominal cross section: 2.5 mm² Screw thread: M3 Note: Please observe the current carrying capacity of the DIN rails. Tightening torque: 0.5 ... 0.8 Nm Stripping length: 8 mm Conductor cross section rigid: 0.2 mm² ... 4 mm² Cross section AWG: 24 ... 12 (converted acc. to IEC) Conductor cross section flexible: 0.2 mm² ... 2.5 mm² Conductor cross section, flexible [AWG]: 24 ... 14 (converted acc. to IEC) Flexible conductor cross section (ferrule with plastic sleeve): 0.2 mm² ... 2.5 mm² Maximum load current: 34 A (with 4 mm² conductor cross section) |
| Dimensions | Width: 5 mm Height: 27.5 mm Depth: 18 mm |
| Material specifications | Color: silver-colored Flammability rating according to UL 94: V0 Insulating material: PA |
| Mechanical properties | Mechanical data Open side panel: Yes |
| Environmental and real-life conditions | Ambient conditions Ambient temperature (operation): -60 °C ... 110 °C (Operating temperature range incl. self-heating; for max. short-term operating temperature, see RTI Elec.) Ambient temperature (storage/transport): -25 °C ... 60 °C (for a short time, not exceeding 24 h, -60 °C to +70 °C) Ambient temperature (assembly): -5 °C ... 70 °C Ambient temperature (actuation): -5 °C ... 70 °C Permissible humidity (operation): 20 % ... 90 % Permissible humidity (storage/transport): 30 % ... 70 % |
| Mounting | Mounting type: NS 15 |
