| Product properties | Product type: Data cable preassembled Sensor type: CANopenî Number of positions: 5 Application: External areas No. of cable outlets: 1 Shielded: yes Coding: A Insulation characteristics Degree of pollution: 3 |
| Interfaces | Bus system: CANopenî/DeviceNetâ⢠Signal type/category: CANopenî DeviceNetâ⢠|
| Signaling | Status display: No Status display present: No |
| Electrical properties | Contact resistance: ââ°¤ 5 mé Insulation resistance: ââ°¥ 100 Mé Nominal voltage UN: 48 VÃAC 60 VÃDC Nominal current IN: 4 A Protective circuit: unwired Transmission medium: Copper |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 100 |
| Material specifications | Flammability rating according to UL 94: V0 Seal material: FPM Material of grip body: PP Contact material: CuSn Contact surface material: Ni/Au Contact carrier material: PP Material for screw connection: Stainless steel |
| Connection data | Pin assignment Contact | Color (signal designation) | Contact (optional): 1 (Socket) | SR (shield) 2 (Socket) | RD (V+) 3 (Socket) | BK (V-) 4 (Socket) | WH (CAN_H) 5 (Socket) | BU (CAN_L) |
| Connector | Connection 1 Type: free cable end Connection 2 Type: Socket straight M12 Number of positions: 5 Coding type: A (Standard) |
| Cable/line | Cable length: 10 m CANopen Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/1e68ea1d8c29454c8e7e36d658f91c6e/-S204x204-FJPG Cable weight: 70 kg/km UL AWM Style: 21281 (80°C/300 V) Number of positions: 4 Shielded: yes Cable type: CANopenî/DeviceNetâ⢠outdoor installation, FRNC, blackÃ[92X] Conductor structure: 2xAWG24/19+2xAWG22/19 Signal runtime: 4.46 ns/m Conductor structure signal line: 19x 0.13 mm AWG signal line: 24 Conductor cross section: 2x 0.25 mm² (Signal) 2x 0.34 mm² (Power) 1x 0.38 mm² (Drain wire) Wire diameter incl. insulation: 1.9 mm (Signal) 1.4 mm (Power) External cable diameter: 6.9 mm ñ0.3Ãmm Outer sheath, material: FRNC External sheath, color: black Conductor material: Tin-plated Cu litz wires Material wire insulation: PE Single wire, color: red-black, blue-white Thickness, insulation: 0.6 mm (Signal) 0.3 mm (Power) Thickness, outer sheath: 1.15 mm Twisted pairs: 2 cores to the pair Type of pair shielding: Aluminum-lined foil Overall twist: 2 pairs around a drain wire in the center to the core Optical shield covering: 70 % Max. conductor resistance: 90 é/km (Signal) 55 é/km (Power) Insulation resistance: ââ°¥ 200 Mé*km (at 20ðC) Wave impedance: 120 é ñ12Ãé (f = 1 MHz) Working capacitance: 39.8 nF (at 1 kHz, core/core) Nominal voltage, cable: ââ°¤ 300 V Test voltage Core/Core: 2000 V (50ÃHz, 1Ãmin.) Test voltage Core/Shield: 2000 V (50ÃHz, 1Ãmin.) Minimum bending radius, fixed installation: 5 x D Minimum bending radius, flexible installation: 10 x D Halogen-free: yes Flame resistance: According to IEC 60332-3-25 (Cat. D) Resistance to oil: yes Other resistance: UV resistant Ambient temperature (operation): -40°C ... 105°C Ambient temperature (installation): -40°C ... 105°C |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP65 IP67 IP68 IP69K Ambient temperature (operation): -40°C ... 105°C (Plug / socket) -40°C ... 85°C (On sudden changes in temperature (according to IEC 60512-11-4)) |
| Standards and regulations | M12 Standard designation: M12 connector Standards/specifications: IEC 61076-2-101 |
