1410688 PHOENIX CONTACT -

NBC-MS/ 5,0-93K/MS SCO - Bus system cable

Assembled Sercos III cable, shielded, star quad, 22 AWG stranded (7-wire), RAL 3020 (traffic red), M12 plug, SPEEDCON, 4-pos. to M12 plug, SPEEDCON, length: 5 m

Cod. Articolo: 1410688 copia - copy

Cod. Fornitore: 1410688 copia - copy

PHOENIX CONTACT

Product properties	Product type: Data cable preassembled Number of positions: 4 No. of cable outlets: 1 Shielded: yes Insulation characteristics Overvoltage category: II Degree of pollution: 3
Electrical properties	Nominal voltage U_N: 48 VÃAC 60 VÃDC Transmission medium: Copper
Mechanical properties	Mechanical data Insertion/withdrawal cycles: Ã¢Ã¢°¥ 100
Material specifications	Flammability rating according to UL 94: V0
Connector	Connection 1 Type: Plug straight M12 Connection 2 Type: Plug straight M12
Cable/line	Cable length: 5 m Sercos IIIÃ[93K] Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/4b34f8ad5d1bc342b90b879ccf8d3910/-S204x204-FJPG Cable weight: 68 kg/km UL AWM Style: 21694 (60Ã°C / 600ÃV) Number of positions: 4 Shielded: yes Cable type: Sercos IIIÃ[93K] Conductor structure: 1x4xAWG22/7, SF/TQ Signal runtime: 5.3 ns/m Conductor structure signal line: 7x 0.25 mm AWG signal line: 22 Conductor cross section: 4x 0.34 mm² Wire diameter incl. insulation: approx. 1.55 mm External cable diameter: 6.5 mm Ã±0.2Ãmm Outer sheath, material: PVC External sheath, color: signal red RAL 3020 Conductor material: Tin-plated Cu litz wires Material wire insulation: PE Single wire, color: white, yellow, blue, orange Thickness, outer sheath: approx. 0.9 mm Type of pair shielding: Aluminum-lined polyester foil Overall twist: Star quad Max. conductor resistance: Ã¢Ã¢°¤ 120 Ã©/km Insulation resistance: Ã¢Ã¢°¥ 0.5 GÃ©*km Coupling resistance: Ã¢Ã¢°¤ 20.00 mÃ©/m (at 10 Hz) Wave impedance: 100 Ã© Ã±15ÃÃ© (at 100 MHz) Nominal voltage, cable: 600 V Test voltage Core/Core: 2000 V (50ÃHz, 1Ãmin.) Test voltage Core/Shield: 2000 V (50ÃHz, 1Ãmin.) Minimum bending radius, fixed installation: 3 x D Minimum bending radius, flexible installation: 7 x D Flame resistance: according to ULÃ1685 (CSA FT 4) Resistance to oil: Resistant to oil to a limited extent Other resistance: UV resistant According to ULÃ1581, Section 1200 Ambient temperature (operation): -40°C ... 70°C (cable, fixed installation) -40°C ... 70°C (Cable, flexible installation) Ambient temperature (installation): -20°C ... 60°C
Environmental and real-life conditions	Ambient conditions Degree of protection: IP65/IP67/IP69K Ambient temperature (operation): -25°C ... 70°C (cable, fixed installation) -25°C ... 70°C (Cable, flexible installation)
