1411026 PHOENIX CONTACT -

SAC-5PY-0,1-920/2XFS SCO - Bus system cable

Bus system cable, CANopen®, DeviceNetÃ¢â¢, 5-position, PUR halogen-free, red lilac RAL 4001, shielded, free cable end, on Socket straight M12 SPEEDCON, coding: A and Socket straight M12 SPEEDCON, coding: A, cable length: 0.1 m, Connector unshielded, Shield connected to pin 1

Cod. Articolo: 1411026 copia - copy

Cod. Fornitore: 1411026 copia - copy

PHOENIX CONTACT

Product properties	Product type: Data cable preassembled Application: Standard Sensor type: CANopenÃ® Number of positions: 5 No. of cable outlets: 1 Shielded: no Coding: A
Interfaces	Bus system: CANopenÃ®/DeviceNetÃ¢Ã¢¢ Signal type/category: CANopenÃ® DeviceNetÃ¢Ã¢¢
Signaling	Status display: no Status display present: No
Electrical properties	Insulation resistance: Ã¢Ã¢°¥ 100 MÃ© Nominal voltage U_N: 48 V AC 60 V DC Nominal current I_N: 4 A Transmission medium: Copper
Material specifications	Seal material: NBR Material of grip body: TPU, hardly inflammable, self-extinguishing Contact material: CuSn Contact surface material: Ni/Au Contact carrier material: TPU GF Material for screw connection: Brass, nickel-plated
Connection data	Pin assignment Contact \| Color (signal designation) \| Contact (optional): 1 (free cable end) \| SR (shield) \| 1 (Socket 1)\| 1 (Socket 2) 2 (free cable end) \| RD (V+) \| 2 (Socket 1)\| 2 (Socket 2) 3 (free cable end) \| BK (V-) \| 3 (Socket 1)\| 3 (Socket 2) 4 (free cable end) \| WH (CAN_H) \| 4 (Socket 1)\| 4 (Socket 2) 5 (free cable end) \| BU (CAN_L) \| 5 (Socket 1)\| 5 (Socket 2)
Connector	Connection 1 Type: free cable end Connection 2 Type: Socket straight M12 SPEEDCON Number of positions: 5 Locking type: SPEEDCON Coding type: A (Standard) Connection 3 Type: Socket straight M12 SPEEDCON Number of positions: 5 Locking type: SPEEDCON Coding type: A (Standard)
Cable/line	Cable length: 0.1 m CANopenÃ®/DeviceNetÃ¢Ã¢¢, PUR, violet [920] Dimensional drawing: https://caas.phoenixcontact.com/caas/v1/stable/media/9116/full/b1500?format=jpg Cable weight: 90 kg/km UL AWM Style: 21198 (80 °C/300 V) Number of positions: 4 Shielded: yes Cable type: CANopenÃ®/DeviceNetÃ¢Ã¢¢, PUR, violet [920] Conductor structure: 2xAWG24/19+2xAWG22/19 Conductor structure signal line: 19x 0.13 mm AWG signal line: 24 Conductor cross section: 2x 0.25 mm² (Data cable) 2x 0.34 mm² (Power supply) 1x 0.34 mm² (Drain wire) Wire diameter incl. insulation: 1.95 mm Ã±0.05 mm (Data cable) 1.4 mm Ã±0.05 mm (Power supply) External cable diameter: 6.70 mm Ã±0.3 mm Outer sheath, material: PUR External sheath, color: red lilac RAL 4001 Conductor material: Tin-plated Cu litz wires Material wire insulation: Foamed PE (Data cable) PE (Power supply) Single wire, color: red-black, blue-white Twisted pairs: 2 cores to the pair Type of pair shielding: Plastic-coated aluminum foil, aluminum side outside Overall twist: 2 pairs around a drain wire in the center to the core Optical shield covering: 80 % Insulation resistance: Ã¢Ã¢°¥ 5 GÃ©km (Data cable) Ã¢Ã¢°¥ 5 GÃ©km (Power supply) Loop resistance: Ã¢Ã¢°¤ 181.80 Ã©/km (Data cable) Ã¢Ã¢°¤ 114.80 Ã©/km (Power supply) Wave impedance: 120 Ã© Ã±10 % (with 1 MHz) Cable capacity: nom. 40 nF/km (Data cable) Nominal voltage, cable: Ã¢Ã¢°¤ 300 V (Peak value, not for high-power applications) Test voltage Core/Core: 2000 V (50 Hz, 1 min.) Test voltage Core/Shield: 2000.00 V (50 Hz, 1 min.) Minimum bending radius, fixed installation: 5 x D Minimum bending radius, flexible installation: 10 x D Smallest bending radius, fixed installation: 34 mm Smallest bending radius, movable installation: 67 mm Dynamic load capacity (bending): Max. bending cycles: 5000000, Bending radius: 70 mm, Bending radius: 10 x D, Traversing path: 4.5 m, Traversing rate: 3 m/s, Acceleration: 3 m/s², Ambient temperature: -20 °C ... 60 °C Shield attenuation: Ã¢Ã¢°¤ 22.9 dB/km (with 1 MHz) Ã¢Ã¢°¤ 16.4 dB/km (At 500 kHz) Ã¢Ã¢°¤ 9.5 dB/km (At 125 kHz) Halogen-free: in accordance with DIN VDE 0472 part 815 according to IEC 60754-1 Flame resistance: IEC 60332-1-2 in accordance with ISO 6722-1 5.22 (UN ECE-R 118.01) Other resistance: Low adhesion Ambient temperature (operation): -40 °C ... 80 °C (cable, fixed installation) -30 °C ... 70 °C (Cable, flexible installation) -20 °C ... 60 °C (for installation) -20 °C ... 60 °C (cable, drag chain applications)
Environmental and real-life conditions	Ambient conditions Degree of protection: IP65 IP67 Ambient temperature (operation): -25 °C ... 90 °C (Plug / socket)
