| Notes | General: This product corresponds to the PROFINET Cabling and Interconnection Technology Guideline for PROFINET regulations, version 2.00, order no: 2.252, Chapter 8.2 Connectors for Outside Environment (Balanced cabling) and chapter 13 Application specific Cabling and Interconnection Technology (AIDA) |
| Product properties | Type: RJ45 Product type: Panel mounting frame Number of positions: 8 Connection profile: RJ45 Number of slots: 1 Insulation characteristics Degree of pollution: 2 |
| Electrical properties | Rated voltage (III/3): 72 V (DC) Rated surge voltage: 1 kV Operating voltage: 72 V (DC) Frequency range: 500 MHz Insulation resistance: > 500 Mé (100ÃVÃDC) Transmission medium: Copper |
| Connection data | Connection technology Connection method: IDC connection |
| Dimensions | Dimensional drawing: https://dam-mdc.phoenixcontact.com/rendition/156443151564/6f9be6270ee08240b2b7b07073aaf6e0/-S204x204-FJPG Width: 22.2 mm Height: 42 mm Length: 51 mm |
| Material specifications | Material: Metal Flammability rating according to UL 94: V0 Seal material: NBR Seal material, pin connector pattern: NBR Housing surface material: nickel-plated Material, protective cover: PC Housing material: Metal |
| Cable/line | Shielded: yes External cable diameter: 4.5 mm ... 9 mm Wire diameter: 0.4 mm ... 0.65 mm Wire diameter including insulation: 0.8 mm ... 1.6 mm |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 750 |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP65/IP67 Ambient temperature (operation): -10°C ... 60°C Ambient temperature (storage/transport): -40°C ... 70°C Ambient temperature (assembly): -5°C ... 55°C |
| Mounting | Connection method: IDC connection |
