| Product properties | Product type: Sensor/actuator cable Number of positions: 8 No. of cable outlets: 1 Shielded: no Coding: A Insulation characteristics Overvoltage category: II Degree of pollution: 3 |
| Material specifications | Flammability rating according to UL 94: HB Seal material: NBR Material of grip body: TPU, hardly inflammable, self-extinguishing Contact material: CuZn Contact surface material: Ni/Au Contact carrier material: TPU GF Material for screw connection: Stainless steel |
| Electrical properties | Insulation resistance: ââ°¥ 100 Mé Nominal voltage UN: 30 V AC 30 V DC Nominal current IN: 2 A |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 100 |
| Signaling | Status display: no Status display present: No |
| Connector | Connection 1 Type: free cable end Connection 2 Type: Socket straight M12 Number of positions: 8 Coding type: A |
| Cable/line | Cable length: 30 m PVC yellow [540] Cable weight: 54 kg/km UL AWM Style: 2464 (80 °C/300 V) Number of positions: 8 Shielded: no Cable type: PVC yellow [540] Conductor structure signal line: 32x 0.10 mm AWG signal line: 24 Conductor cross section: 8x 0.25 mm² Wire diameter incl. insulation: 1.19 mm ñ0.02 mm External cable diameter: 5.90 mm ñ0.2 mm Outer sheath, material: PVC External sheath, color: yellow Conductor material: Bare Cu litz wires Material wire insulation: PVC Single wire, color: white, brown, green, yellow, gray, pink, blue, red Thickness, insulation: ââ°¥ 0.23 mm Thickness, outer sheath: ââ°¥ 0.76 mm Overall twist: 8 wires around filler to the core Length of twist, overall twist: 77 mm Max. conductor resistance: 78 é/km (at 20 °C) Insulation resistance: ââ°¥ 200 Mé*km (at 20 °C) Working capacitance: approx. 107 pF Nominal voltage, cable: ââ°¤ 300 V AC Test voltage: ââ°¥ 3000 V AC (Spark test) Minimum bending radius, fixed installation: 5 x D Minimum bending radius, flexible installation: 10 x D Smallest bending radius, fixed installation: 30 mm Smallest bending radius, movable installation: 59 mm Flame resistance: According to UL 758/1581 (Cable Flame) according to UL 758/1581 FT1 Resistance to oil: According to DIN EN 60811-2-1, 168 h at 80 °C Ambient temperature (operation): -40 °C ... 80 °C (cable, fixed installation) -25 °C ... 80 °C (Cable, flexible installation) |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP65 IP68 Ambient temperature (operation): -25 °C ... 90 °C (Plug / socket) |
| Standards and regulations | Standard designation: M12 connector Standards/specifications: IEC 61076-2-101 |
