| Product properties | Type: RJ45 Product type: Data connector (cable side) Sensor type: Ethernet/PROFINET Number of positions: 8 Connection profile: RJ45 No. of cable outlets: 1 Shielded: no Cable outlet: straight Insulation characteristics Overvoltage category: I Degree of pollution: 2 |
| Electrical properties | Rated voltage (III/3): 72 V (DC) Rated current: 1 A Frequency range: to 250 MHz Nominal voltage UN: 72 V (DC) Nominal current IN: 1.75 A Transmission medium: Copper Transmission characteristics (category): CAT6 Transmission speed: 1 Gbps |
| Connection data | Connection technology Connection method: Crimp connection Connection cross section AWG: 27 ... 24 (flexible) Conductor cross section: 0.1 mm² ... 0.2 mm² (flexible) |
| Dimensions | Width: 38.4 mm Height: 19.9 mm Length: 53 mm |
| Material specifications | Color: gray Flammability rating according to UL 94: V0 Seal material cable seal: TPE Cable seal material: NBR Contact material: Phosphor bronze Contact surface material: Gold Contact carrier material: PC O-ring material: FPM Housing material: Plastic |
| Cable/line | External cable diameter (): 5 mm ... 8.5 mm Cable cross section: 0.1 mm² |
| Mechanical properties | Mechanical data Insertion/withdrawal cycles: ââ°¥ 750 |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP67 Ambient temperature (operation): -25°C ... 60°C |
| Mounting | Connection method: Crimp connection |
