| Product properties | Product type: Data cable by the meter Sensor type: PROFIBUS PA Number of positions: 2 Shielded: yes |
| Electrical properties | Transmission medium: Copper |
| Interfaces | Signal type/category: PROFIBUS PA, 31.25 kbps FOUNDATION Fieldbus, 31.25 kbps |
| Cable/line | Cable length: 500 m PROFIBUS PA [913] UL AWM Style: 2464 Number of positions: 2 Shielded: yes Cable type: PROFIBUS PA [913] Conductor structure: 2xAWG18/7 + 1xAWG20/7 Signal speed: 0.77 c Conductor structure signal line: 7x 0.40 mm AWG signal line: 18 Conductor cross section: 2x 0.75 mm² (Signal line) 1x 0.5 mm² (Drain wire) Wire diameter incl. insulation: 2.5 mm ñ0.05 mm External cable diameter: 7.80 mm Outer sheath, material: PVC External sheath, color: black Conductor material: Tin-plated Cu litz wires Material wire insulation: Foamed PE Single wire, color: red, green Thickness, insulation: 0.65 mm Thickness, outer sheath: 1.00 mm Twisted pairs: 2 cores to the pair Overall twist: One pair with one drain wire and fillers for core Optical shield covering: 70 % Max. conductor resistance: 20.5 é/km (Signal line) 9 é/km (shield) Cable capacity: 80 nF/km (Line-line) 4 nF/km (Line-shield) Cable impedance: 100 é ñ20 % (At 31.25 kHz) Nominal voltage, cable: 300 V Tensile strength: 80 N Flame resistance: according to IEC 60332-1 Resistance to oil: According to ICEA S82-552 Other resistance: UV resistant (according to UL 1581, Section 1200) Ambient temperature (operation): -30 °C ... 75 °C Ambient temperature (installation): -5 °C ... 80 °C |
