| Product properties | Product type: Data cable preassembled Sensor type: Ethernet Number of positions: 4 No. of conductors: 4 |
| Electrical properties | Attenuation: typ. 0.2 dB max. 0.6 dB Transmission medium: Multi-mode fiberglass |
| Mechanical properties | Tensile strength short-term/long-term: 30 N |
| Material specifications | Flammability rating according to UL 94: V0 Ferrule material: Zirconia ceramics Outer sheath, material: LSFH |
| Connector | Connection 1 Insertion/withdrawal cycles: 1000 Degree of protection: IP68 (IEC 60529) IP68 Ambient temperature (operation): -20°C ... 70°C (IEC 60794-1-2 F1) Number of positions: 4 Locking type: Screw locking mechanism Connection 2 Material: Plastic Number of positions: 4 Degree of protection: IP20 (IEC 60529) Locking type: Push Pull |
| Cable/line | Cable length: 2 m Cable weight: 3.00 kg/km Cable type: Multimode fiberglass Zip cord, fiberglass Outer sheath, material: LSFH External sheath, color: orange Individual wire diameter: 250 õm Tensile strength short-term/long-term: 30 N Halogen-free: complying with IEC 60754-1/2 FO cable Number of fibers: 4 Fiber: 62.5/125Ãõm OM1 Fiber type: Multimode fiberglass 62.5/125Ãõm Transmission medium: Multi-mode fiberglass |
| Environmental and real-life conditions | Ambient conditions Degree of protection: IP68 Ambient temperature (operation): -40°C ... 85°C (IEC 61300-2-22) Shock: 100g, according to IEC 61300-2-9 |
